Product Details:
Payment & Shipping Terms:
|
Usage: | Universal Testing Machine | Temp. Uniformity: | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
---|---|---|---|
Exterior Material: | Stainless Steel Plate | Standard: | Standard And Customized |
Temp. Range: | 50º C-300º C | Insulation Material: | Glass Wool |
Safety Devices: | No Fuse Breaker, Over Temp Protection, Ceramic Fuse | Power: | AC 380V±10% 3Φ4wire 50Hz/60Hz |
Temp. Constancy: | ±1.0 ºC | Product Name: | Stability Vacuum Oven Supplies |
High Light: | laboratory drying oven,vacuum drying oven |
High low temperature controlled cabinet industrial hot air circulation oven
Application
Features
1) Microcomputer electronic digital control, precision & reliability.
2) High temperature endurance & non-aging.
3) SUS#304 stainless steel inner chamber and excellent argon arc welding.
4) Forced circulation air, the temperature rise fast, even distribution.
5) PID control, double overheating protection, safety and reliability.
6) Two groups of moving plates can be adjusted height.
Technical parameter
Specifications of drying oven | |||||
Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 |
Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 |
Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 |
Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 |
Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | |||
Temp. range | 50 ºC~ 200 ºC( 300 ºC) | ||||
Temp. constancy | ±1.0 ºC | ||||
Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | ||||
Heat up time | 50 ºC to 200 ºC within 50 min | ||||
Interior material | Stainless steel plate | ||||
Exterior material | Painted Stainless steel plate | ||||
Insulation material | Glass wool | ||||
Safety devices | No fuse breaker, over temp protection, ceramic fuse | ||||
Accessories | Recorder, insolating layer | ||||
Note: 1. We reserve the right to change specifications without prior notice |
specifications
|
||||
Model
|
KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 |
Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 |
Capacity(KVA) | 6.5 | 7.5 | 8.5 |
9.5
|
Power |
AC 380V±10% 3Φ4wire 50Hz/60Hz
|
|||
Temp. range |
50 ºC~ 200 ºC( 300 ºC)
|
|||
Temp. constancy |
±1.0 ºC
|
|||
Temp. uniformity |
±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
|
|||
Heat up time |
50 ºC to 200 ºC within 50 min
|
|||
Interior material |
Stainless steel plate
|
|||
Exterior material |
Painted Stainless steel plate
|
|||
Insulation material |
Glass wool
|
|||
Safety devices
|
No fuse breaker, over temp protection, ceramic fuse | |||
Accessories
|
Recorder, insolating layer | |||
Note: 1. We reserve the right to change specifications without prior notice
|
1,Pre-sales service
Before the purchase, our company will provide customers with detailed product-related information, and welcome you to visit the company and check the goods.
2,After-sales service
After the completion of the transaction, our company will be arranged different after-sales service according to the ease of the goods , and even arrange work engineers on-site service.
3,Warranty period
Our product warranty is 12 months and we are committed to responding within 48 hours of the problem, providing a solution.
