Home ProductsClimatic Test Chamber

Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability

China KOMEG Technology Ind Co., Limited certification
China KOMEG Technology Ind Co., Limited certification
Fast delivery and quality products.

—— Gozia

Friendly and pleasant cooperator, "I like the factory, I like the design, I like the workstyle"

—— Wagner

The design and quality impress me a lot.

—— Mr Yee

" A trustworthy supplier of climatic test chamber".

—— Denis

I'm Online Chat Now

Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability

Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability
Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability

Large Image :  Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: KOMEG
Certification: CE, ISO9001
Model Number: KMH-150L
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: FOB 4600~15000USD/SET
Packaging Details: Packed with film firstly, and then reinforced with wooden case for outer packing
Delivery Time: 20-30 days upon receive your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1, 000~1, 500 SETS / YEAR
Detailed Product Description
External Chamber Material: Plate+painting Or Stainless Steel For Choose Controller: Programmable LCD Touch Screen
Humidity Uniformity: ±3.0% Or ±5.0% Humidity Range: 10~98%
Temperature Range: -70 °C To 150/180 °C Compressor: Original France Tecumseh
Usage: Universal Testing Machine Temp. Uniformity: ±2.0ºC
Humidity Constancy: ±2.5%R.H Ambient Temp.: +5°C ~+35°C
High Light:

Environmental Test Chamber

,

Climatic Testing Chamber



Refrigeration Temperture and Humidity Testing Chamber for Lab is for Testing Material Heat, Cold, Dry Resistance





Product Application



Refrigeration Temperture and Humidity Testing Chamber for Lab is for testing material heat, cold, dry resistance, humidity resistance.Suitable for electronics, electrical appliances,Communications, instrumentation, vehicles, plastic products, metal, food, chemical,building materials, medical, aerospaceand other products.





Environmental test chamber Standard



GJB150.3 high-temperature testing



GJB150.4 low-temperature testing



GJB150.9 humid testing



GB11158 Technical conditions for high-temperature testing box



GB10589-89 Technical conditions for low-temperature testing box



GB10592-89 Technical conditions for high and low temperature testing box



B/T10586-89 technical conditions for humidity testing chamber



GB/T2423.1-2001 Low-temperature testing methods



GB/T2423.2-2001 High-temperature testing methods



B/T2423.3-93 Testing Method for humidity Test Chamber



GB/T2423.4-93 Alternating hot and humid testing method



GB/T2423.22-2001temperature testing method



IEC60068-2-1.1990 low-temperature testing method



IEC60068-2-2.1974 high-temperature testing method





Specifications



KMH-S series( -70°C ~150°C)


Model KMH-S series
150S 225S 408S 800S 1000S
Temp. range -70°C ~150°C
Interior sizel W(mm) 600(mm) 700(mm) 700(mm) 1000(mm) 1000(mm)
H(mm) 600(mm) 700(mm) 750(mm) 1000(mm) 1000(mm)
D(mm) 460(mm) 480(mm) 800(mm) 800(mm) 1000(mm)
Exterior size W(mm) 880(mm) 980(mm) 980(mm) 1280(mm) 1280(mm)
H(mm) 1730(mm) 1890(mm) 1940(mm) 2160(mm) 2160(mm)
D(mm) 1400(mm) 1460(mm) 1740(mm) 1750(mm) 1950(mm)
Power(KW) 5.8 6 7.5 12.8 12.8
Weight(KG) 280 330 450 550 650
Humidity uniformity ±3.0%R.H ±5.0%R.H
Heat up time -70°C ~+100°C ,within 60 min
Pull down time +20°C ~-70°C , within 80 min
Humidity Range 20~98%R.H
Temp. constancy ±0.5ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0ºC
Safety device (standard) NFB, over pressure,over heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid polyurethane Foam and Glass Fiber Wool
Ambient Temp. +5°C ~+35°C
Wiring method AC 380±10% 50Hz ,3 phase 4 wires +Ground Wires
Controller LCD Touch Screen, Chinese or English display selectable
Operation model :Program or fix point running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles





By testing your product with our low cost environmental test chamber you can:

  • Shorten Product Development Period
  • Increase Customers' Confidence and Loyalty
  • Ensure Product Quality & Reliability
  • Forecast Life Expectancy
  • Reduce Costs
  • Increase Profitability
  • Reduce After Sales Service



Environmental Test Chambers (ETC) are mainly and widely used for various types of testing such as prototype evaluation, research & development testing, production quality control testing, accelerated stress testing, reliability testing, failure analysis, and any other application where environmental simulation is needed.



Main Features

1. Has the USB download function, with RS232 interface, the curve of the software, do not need recorder



2. With vacuum glass observation window, direct observation of the function more effectively



3. The refrigerant servo control valve flow calculation. Save electricity 30%, dormancy in flow time, energy saving more than 50%



4. Preventing electromagnetic interference by certification controller; At least 32 digital soft path matching with the Times development and software upgrade function



  5. Defrost cycle (800 cycle defrost time, defrosting guarantee within 2 hours each time, integration test    reach 25% of the energy saving province electricity)





Packing and Shipment:



(1).Strong standard wood case, inner plastic films wrapped for temperature and humidity test chamber

(2).Usually we delivery the equipment by air,by sea or by express. it depends on customer.






FAQ:



Q1 : Can you customize the product?



A: Yes, we can customize any products according to requirements.



Q2 : How to choose the most suitable products?



A: Our professional team will give you the best suggestion,just be patiently to tell us the information about the parameters your required.



Q3 : Can you arrange installations and commissioning in our lab?



A: Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate;



Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it;



Thirdly, some of customized chambers we should to install and teach your team to operate.





Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability 0





Professional Lab Temperature And Humidity Test Chamber For Testing Material Reliability 1



Specification for KMH-1000R(10%~98%RH).pdf
