KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test

KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test
KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test
video play

Large Image :  KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test

Product Details:
Place of Origin: China,Dongguan
Brand Name: KOMEG
Certification: CE/ROHS/FCC/ISO
Model Number: KMHW-36S
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T /C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 50 sets per month
Detailed Product Description
Product Name: Walk-in Climatic Test Chambers Temp. Uniformity: +/-2
Temp Fluctuation: +/-0.5 Delivery: 30-35 Working Days
Application: Reliability Testing, Research & Development Testing, Failure Analysis Ambient Temperature: +5℃~+35℃
Humidity Uniformity: +/-3%RH(>75%) +/-5%RH(≤75%) Humidity Fluctuation: +/-2.5%RH
High Light:

walk in environmental chamber

,

walk in climatic chamber

Walk in stability Climatic Aging Test Chamber for Vehicle driving test


1.Applications

KOMEG Walk In Environmental Chamber is consist of Control Panel, electrical panels, moisturizingplate blower,heater,humidifier, freezer. It provides a large spare to test the temperature and humidityfor large-scaleparts,semi-finished products, it applied to test products that large-scale or the quantity, such as: computer terminals,vehicle parts.



2.Corresponding standard:

GB-2423. 1-89(IEC68-2-1) Test A: Low Temperature Test

GB-2423. 2-89(IEC68-2-2) Test B: High Temperature Test

GJB360. 8-87(MIL-STD.202F) High Temperature Operating Life Test

GBJl50. 3(MIL-STD-810D) High Temperature Test

GJBl50. 4(MIL-STD-810D) Low Temperature Test

GB2423. 3-93(IEC68-2-3) Test Ca: method for steady-state damp heat test

GB2423. 4-93(IEC68-2—30) Test Db: Damp Heat Alternative Test

GJBl50. 9-93(MIL-STD-810D) Damp Heat Test


3. Main Technical Parameters

Model

KMHW-36(walk-in room) (Customize is acceptable)

Volume(m³)

36CBM

Interior Dimensions

W 3000 × H 4000 × D 3000 mm

Exterior Dimensions

W 3550 × H 4300 × D 5400 mm

Safety Devices(standard)

No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection

Standard accessories

Sight window*1, cable port ( portΦ50mm ) *1, chamber lamp*1, status indicator

Control System

 Balanced Temperature & Humidity Control System

Refrigeration system

Water Cooled

Semi-hermetic compressor, single stage or cascade refrigeration system,

CFC free refrigerant ( HFC-507 and HFC-23 )

Controller

Panel

7-inch LCD Touch panel, Chinese or English display selectable

Operation model

Program or fix point running

Memory capacity

120 programs,1200steps, all repeat 999 cycles,part repeat 99 cycles

Accuracy

Temp.:0.1% of F.S ± 1 digit  Humidity:0.1% of F.S ± 1 digit

Input

Temp.: pt-100, Humidity: pt-100 or ~5V DCV

Comm.port

 RS-232 or RS-485 ( Softawre is option)

Temp. range

Maximum: 80 ºC,120 ºC;
Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC

Humidity Range

10%, 20%, 30% ~ 95%

Temp. constancy

±0.5 ºC

Humidity constancy

±2.5%R.H

Temp. uniformity

±2.0 ºC

Humidity uniformity

±5.0%R.H

Ambient Temp.

+5 ºC~+35 ºC

Wiring method

AC 380 ± 10% 50Hz ,3 phase 4 wires + Ground Wires

Heat up time

 +20 ºC~+80 ºC, Within 60 min

Pull down time

 +20 ºC ~ -55 º,  -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60  min

Interior material

Stainless Steel Plate(SUS 304)

Exterior material

Baked Painting Steel Or Stainless steel ( SUS304)

Insulation material

Rigid polyurethane foam

Door size (mm)

Single wing: W800 x H1800;  Double wing: W1600 x H1800;

Note:1. We reserve the right to change specifications without prior notice   2.Customized sizes and configurations available




4.  Features:



a. The chamber is assembled with self-made storeroom boards. The dimension and shape of it can be changed freely. It is assembled on site and can be transported, carries and relocated conveniently. The special silicon rubber imported from Japan is utilized as the base material for sealing and contracting for the assemble seams. The self-made storeroom boards employ the design and processing technology of frame structure, setting steel plates into the frame as inner part and outer covering and foaming into a whole body that boasts the distinctive features of high tightness, perfect sealing, wide range of temperature and humidity resisting, good warmness reserving and long life etc. of the industry.



b. Non-frosting operation and automatic defrosting loop, continuous operation in low humidity and temperature.



c. The 7〃large color control screen comprehensively displays the operating states.

d. The precooling and preheating temperature are set automatically based on reset time. The operating state of the chamber can be adjusted to its best, which can save up to 50% of energy compared with the old model.

e. It is characterized by low error, high wind speed and uniform exposure of samples.

f. With the low noise design, the level of noise is controlled under 72db.




5. Walk-in Room Show

KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test 0

KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test 1

KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test 2

6. About KOMEG



KOMEG is pioneer supplier for Environmental Testing Chamber in China with over 28 years’ experience. Our products include Climatic Test Chambers, Thermal Shock Test Chambers, walk-in Chambers, Drive-in Chamber, Burn-in rooms, Aging Test Chambers, Vibration Chamber, Temperature Humidity and Vibration three integrated Test Chamber, Drying Ovens, Salt Spray Testers and Medical Laboratory Equipment etc.



7. Package



KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test 3



8. Related products:

KOMEG Walk-in Chamber Test Chambers , Aging Test Chamber For Vehicle Driving Test 4



Temperature Humidity Test Chamber Series:

36L, 64L, 150L, 225L, 408L, 800L, 1000L, 1500L,2360L, 3000L and etc.

Walk in Chamber / Walk in Climatic Test Chamber / Walk in Temperature and Humidity Test Chamber / Aging Chamber series:

10CBM, 13CBM, 24CBM, 27CBM, 45CBM, 256CBM, 300CBM, 485CBM, 520CBM and etc.
