53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃

53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃
53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃
video play

Large Image :  53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃

Product Details:
Place of Origin: China
Brand Name: KOMEG
Certification: CE/ROHS/FCC/
Model Number: KMHW-53L(Walk-in Chamber)
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment30 work days upon deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability: 1, 000~1, 500 SETS / YEAR
Detailed Product Description
Temperature Range: -10℃ ~ +80℃ Temp.fluctuation: ±5.0℃
Temp.Uniformity: ±2.0℃ Humidity Range: 20%~98%RH
Humidity Deviation: ≦±3.0%RH,≦±5.0%RH,
High Light:

walk in humidity chamber


walk in climatic chamber

Temperature range -10℃ ~ +80℃ 53L super long walk-In constant temperature and humidity chamber



A KOMEG Walk-In Chamber serves as a test site for large components, assemblies, and finished


products in electrical and electronics, aerospace, batteries and automobiles, etc. KOMEG manufactures


both Static Walk-In Chambers and Dynamic Walk-In Chambers and can be configured as a temperature


chamber or a temperature humidity chamber.


The KMHW-Series walk-in temperature and climate test chambers are especially developed for large test


specimens. Size and design are optimal loading of test specimens. The modular construction and


variability in size and equipment is ideally for specific application.





● GB-2423.1-2008 (IEC68-2-1) Test A: Low Temperature Test


● GB-2423.2-2008 (IEC68-2-2) Test B: High Temperature Test


● GJB360. 8-87(MIL-STD. 202F) High Temperature Life Test


● GBJl50. 3(MIL-STD-810D) High Temperature Test


● GJBl50. 4(MIL-STD-810D) Low Temperature Test


● GB2423. 3-93(IEC68-2-3)Test Ca: Constant Heat Test


● GB2423. 4-93(IEC68-2—30)Test Db: Damp Heat Alternative Test


● GJBl50. 9-93(MIL-STD-810D) Damp Heat Test






IV. Main Technical Parameters

(Performance: Air-cooled, Room temperature +25°C, no load)

1.Temperature range -10℃ ~ +80℃
2. Temp. Deviation ±2.0℃
3.Temp.Fluctuation ±0.5℃
4. Temp.Uniformity  ±2.0℃
5. Humidity range 20%~98%RH
6.Temperature and humidity range



7.Humidity deviation



8.Humidity Uniformity ±3.0%RH
9.Humidity fluctuation ±2.0%RH
10. Air exchange rate The amount of air per hour is about 1 or 2 times.
11.Cleanliness level Cleanliness level ISO 5 (Use environmental cleanliness level :ISO 6)
Temperature and humidity performance measurement comply with related regulation of IEC60068-3 standard; Sensors placed in the air outlet.
Ⅴ. Chamber Structure (on-site installation)
1. Chamber size

Workspace volume: W 2500 × H 3500 × D 6000 mm

Exterior size: W 2700 × H 4600 × D 8000mm

Chiller size:W 2500 × H 2100 × D 1900mm

2. Insulation box

 wall material: high-quality carbon steel with static color spray

 inner wall material: SUS304 # matte stainless steel plate

 Insulation material: 50mm rigid polyurethane foam insulation + glass fiber. (5 surface insulation, no floor)

3. Door Double door, Door size (1250+1250)*H1350 mm, including window (W400XH550mm).
4. Lighting device Moisture-proof lighting with explosion-proof lampshade.
5.Electric control box Total power circuit breaker, over-temperature protection.
6.Pressure balance The test chamber has a pressure balance port 1 to prevent the pressure in the chamber from being too high.
7. Control method Forced circulation ventilation, Balanced thermostat conditioning (BTHC).
8. Heating High-quality nickel-chromium alloy wire heater, non-contact control mode (SSR).
9. Humidifying Stainless steel corrosion resistance heat evaporation humidification.
10.Pure water machine Pure water machine type 1, please provide 1 ~ 2kg/cm2 tap water source.
11.Humidity Sensor Electronic humidity sensor, no need to replace the wet cloth.
12.Condensate outlet Equipped with studio condensate and unit condensate drain holes.
13.High efficiency filter HEPA * 1, High efficiency 99.99%
14.Ventilation fan High static pressure ventilation fan *1(New air inlet with medium HEPA *1, High efficiency 85%)
15.Differential pressure gaug Differential pressure gaug 0 – 50 mmH2O *1

Product details


53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃ 0




Chambers are covered with air bubble film before put them into the strong plywoodcase, which not only


has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic,


odorless, moisture corrosion, crash-proof, etc


53L Super Long Environmental Room Humidity And Temperature Range -10℃ ~ +80℃ 1



After-sales Service and Training


Charge-free warranty will last for 1 year from the date of equipment acceptance. After the warranty


period, the user will be charged properly. Irregular examination and life-long service are available;


Note: If needed, provide 2 operators for on-site installation and training



Company introduction:


Since 1990, manufacturers of custom environmental chambers and standard environmental chambers,


Specializing in environmental simulation equipment, ess, walk-in, environmental stress screening, altitude


chambers, temperature chambers, temperature and humidity chambers, environmental test chamber


manufacturers, humidity chambers, humidity simulation, temperature cycling, thermal test chambers, solar


panel test chambers, thermal shock, climatic/climate chambers, vibration test chambers, drive-in


chambers, laboratory test chambers, environment test rooms.
