12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber

12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber
12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber
video play

Large Image :  12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber

Product Details:
Place of Origin: China
Brand Name: KOMEG
Certification: CE/ROHS/FCC/
Model Number: KMHW-21L(Walk-in Chamber)
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment30 work days upon deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability: 1, 000~1, 500 SETS / YEAR
Detailed Product Description
Temperature Range: +27℃ ~ +35℃ Temp.fluctuation: ±0.5℃
Temp.Uniformity: ±2.0℃ Humidity Range: 20%~98%RH
Humidity Deviation: ±3.0%RH(>75%RH) ±5.0%RH(≤75%RH) Interior Size: W 2500 × H 2000 × D 2500 Mm
High Light:

walk in humidity chamber


walk in climatic chamber


Temperature range +27℃ ~ +35℃ 12 L laboratory walk-In constant Temperature and humidity chamber



A KOMEG Walk-In Chamber serves as a test site for large components, assemblies, and finished


products in electrical and electronics, aerospace, batteries and automobiles, etc. KOMEG manufactures


both Static Walk-In Chambers and Dynamic Walk-In Chambers and can be configured as a temperature


chamber or a temperature humidity chamber.


The KMHW-Series walk-in temperature and climate test chambers are especially developed for large test


specimens. Size and design are optimal loading of test specimens. The modular construction and


variability in size and equipment is ideally for specific application.





● GB-2423.1-2008 (IEC68-2-1) Test A: Low Temperature Test


● GB-2423.2-2008 (IEC68-2-2) Test B: High Temperature Test


● GJB360. 8-87(MIL-STD. 202F) High Temperature Life Test


● GBJl50. 3(MIL-STD-810D) High Temperature Test


● GJBl50. 4(MIL-STD-810D) Low Temperature Test


● GB2423. 3-93(IEC68-2-3)Test Ca: Constant Heat Test


● GB2423. 4-93(IEC68-2—30)Test Db: Damp Heat Alternative Test


● GJBl50. 9-93(MIL-STD-810D) Damp Heat Test






1.1Temperature range +27℃ ~ +35℃
1.2Temp. Deviation ≦±2.0℃
1.3Temp.Fluctuation ±0.5℃
1.4Temp.Uniformity ≦2.0℃
2.1 Humidity range 40%~90%RH
2.2Temperature and humidity range





2.3Humidity deviation



2.4Humidity Uniformity ±3.0%RH(no-load)
2.5Humidity fluctuation ±2.0%RH
Temperature and humidity performance measurement comply with related regulation of IEC60068-3 standard; Sensors placed in the air outlet.
. Chamber Structure (on-site installation)
1. Chamber size

Workspace volume: W 2500 × H 2000 × D 2500 mm

Exterior size: W 3430 × H 2050 × D 2600 mm (not including the machine protruding part)

2. Insulation box

wall material: high-quality carbon steel with static color spray

inner wall material: SUS304 # matte stainless steel plate

Insulation material: 50mm rigid polyurethane foam insulation + glass fiber. (5 surface insulation, no floor)

3. Door Single door, Door size W900*H1900 mm, including window (Specific size, Depending on design).
4. Lighting device 4 moisture-proof incandescent lamps.
5.Electric control box Total power circuit breaker, over-temperature protection.
6.Pressure balance The test chamber has a pressure balance port 1 to prevent the pressure in the chamber from being too high.
7. Control method Forced circulation ventilation, Balanced thermostat conditioning (BTHC).
8. Heating High-quality nickel-chromium alloy wire heater, non-contact control mode (SSR).
9. Humidifying Stainless steel corrosion resistance heat evaporation humidification.
10.Pure water machine Pure water machine type 1, please provide 1 ~ 2kg/cm2 tap water source.
12.Humidity Sensor Electronic humidity sensor, no need to replace the wet cloth.
13.Condensate outlet Equipped with studio condensate and unit condensate drain holes.

Product details


12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber 0




Chambers are covered with air bubble film before put them into the strong plywoodcase, which not only


has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic,


odorless, moisture corrosion, crash-proof, etc


12 L Laboratory Walk-In Chamber , Constant Temperature And Humidity Control Chamber 1



After-sales Service and Training


Charge-free warranty will last for 1 year from the date of equipment acceptance. After the warranty


period, the user will be charged properly. Irregular examination and life-long service are available;


Note: If needed, provide 2 operators for on-site installation and training
