Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test

Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test
Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test
video play

Large Image :  Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test

Product Details:
Place of Origin: China, Guangdong
Brand Name: KOMEG
Certification: CE, ISO
Model Number: TST-360A
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: negotiation
Packaging Details: Packed with film firstly, and then reinforced with wooden case for outer packing
Delivery Time: 50 days upon your deposit
Payment Terms: T/T, negotiable
Supply Ability: 1, 000 SETS / YEAR
Detailed Product Description
Application: Indoor, Lab, Testing Center In LED Industry High Temperature Chamber: +60~200℃
Conversion Time: 3 Min Internal Volume: 1000L
Test Chamber Temp. Range: -40ºC~+150ºC Cooling Method: Water Cooled
High Light:

thermal shock chamber

,

environmental testing chambers

Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test



Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test 0





KOMEG specification for KTS-72A.pdf

company profile.pdf



1. Specifications



Model
TST-A Series
70A 130A 226A 360A 500A
Test weight(KG) 5 5 5 5 10
Interior size W(mm) 410 520 610 710 810
H(mm) 560 670 770 830 710
D(mm) 410 520 610 770 860
Basket size W(mm) 300 410 510 610 710
H(mm) 300 410 510 730 610
D(mm) 300 410 510 510 730
Low Temp. chamber -55ºC~-10ºC
Pre-cooling time +20ºC~-55ºC, Within 60 min
Test. chamber -40ºC~+150ºC
High Temp. chamber +60ºC~+200ºC
Pre-heating time +60ºC~+200ºC ,Within 25 min
Recovery time High-Temp Exposure 30 min
Low-Temp Exposure 30 min
Recovery time within 3 min
Safety device

No fuse breaker, over pressure, over heat and over current protection

for compressor,over temperature protection, over load protection for blower, dry heat protection

Standard accessory Cable port(portΦ50mm)*1, shelves*2
Interior material Stainless steel plate(SUS 304)
Exterior material Baked painting steel or stainless steel(SUS304)
Insulation material Rigid polyurethane Foam+glass fiber wool
Refrigeration system Water Cooled

Semi-hermetic compressor, cascade refrigeration system,

CFC free refrigerant(HFC-507 and HFC-23)

Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model:Program or fix point running
Memory capacity:120programs,1200steps, all repeat 999cycles,part repeat 99 cycles.
Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit
Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV
Ambient Temp. +5ºC~+35ºC
Power AC 380±10% 50Hz ,3 phase 4 wires +Ground Wires
Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available



2. Application



The rubber thermal shock climatic chamber, indispensable in materials industry such as metal, plastic, rubber, electronics etc, is applicable to test temperature endurance of material structure and composite materials under a rapid shift from extremely high temperature to a extremely low temperature or reverse, so as to find in shortest time the chemical changes or physical damages caused by thermal expansion and contraction.



3. Below are differences between 3-zone and 2-zone thermal shock chamber:



3-zone thermal shock chamber:



three chamber in total: test space, high temp. chamber and low temp. chamber;

Advantage: slight limitation for test sample’s weight, the test sample keep still, this can reduce the impact to samples by moving it, can be used for on-load testing.



Compared with 2-zone type, relatively low failure rate, low cost.



2-zone thermal shock chamber:



Only two chambers: high temp. Chamber and low temp. chamber

Advantage: short conversion time, smaller space needed

Disadvantage: test sample moving. test samples’ size is limited by the basket size



4.Introduction of thermal shock chamber



1.2 ​Corresponding standard:

1 GB/T2423.1-1989 low-temperature testing method
2 GB/T2423.2-1989 high-temperature testing method
3 GB/T2423.22-1989 change temperature test
4 GJB150.5-86 temperature impact test
5 GJB360.7-87 temperature impact test
6 GJB367.2-87 405 temperature impact test



5. About thermal shock test chamber:

Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test 1

Cool And Heating Environmental Thermal Shock Test Chamber For Thermal Cycling Test 2
