Large Capacity Walk In Industrial Drying Oven with Factory Price

Large Capacity Walk In Industrial Drying Oven with Factory Price
Large Capacity Walk In Industrial Drying Oven with Factory Price
video play

Large Image :  Large Capacity Walk In Industrial Drying Oven with Factory Price

Product Details:
Place of Origin: guangdong
Brand Name: KOMEG
Certification: CE
Model Number: KOV-429
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece drying oven
Price: USD2000-USD20000/ piece
Packaging Details: Strong Plywood Case, Meet International Standard
Delivery Time: 25 to 35 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 pieces a year
Detailed Product Description
Item: Industrial Drying Ovens Type: Forced Hot Air Circulation
Power: AC 380V±10% 3Φ4wire 50Hz/60Hz Temp. Range: 50 ºC~ 200 ºC( 300 ºC)
Temp. Constancy: ±1.0 ºC Temp. Uniformity: ±2.0 ºC
Customizable: Yes Exterior Material: Stainless Steel Plate
High Light:

laboratory drying oven

,

large industrial ovens


Large Capacity Walk In Industrial Drying Oven with Factory Price

Over View

Laboratory ovens are ovens for high-forced volume thermal convection applications. These ovens generally provide uniform temperatures throughout. Process applications for laboratory ovens can be for annealing, die-bond curing, drying, Polyimide baking, sterilizing, and other industrial laboratory functions. Typical sizes are from one cubic foot to 0.9 cubic metres (32 cu ft) with temperatures that can be over 340 degrees Celsius.

Laboratory ovens can be used in numerous different applications and configurations, including clean rooms, forced convection, horizontal airflow, inert atmosphere, natural convection, and pass through.

Some of the types of industries that typically use these laboratory ovens are the healthcare industry, technology industry, and transportation industry.Civil engineering laboratories use ovens for drying asphalt, soil, rock, or concrete samples.

Standards Met and Implemented:
GB-2423.2-89(IEC68-2-2)Test B: High Temperature Test
GJB360.8-87(MIL-STD.202F) High Temperature Life Test
GBJl50.3(MIL-STD-810D) High Temperature Test


Specifications of drying oven
Model KOV-50 KOV-100 KOV-200 KOV-290 KOV-500
Interior size (W*H*D)mm 400*350*350 450*500*450 600*600*600 600*950*500 800*1050*600
Exterior size (W*H*D)mm 1010*650*760 1110*800*1100 1260*900*1100 870*1590*640 1160*1760*880
Capacity(KVA) 3.5 3.5 4.5 4.5 6
Power AC220V±10% 1Φ 50Hz/60Hz AC 380V±10% 3Φ4wire 50Hz/60Hz
Temp. range 50 ºC~ 200 ºC( 300 ºC)
Temp. constancy ±1.0 ºC
Temp. uniformity ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
Heat up time 50 ºC to 200 ºC within 50 min
Interior material Stainless steel plate
Exterior material Painted Stainless steel plate
Insulation material Glass wool
Safety devices No fuse breaker, over temp protection, ceramic fuse
Accessories Recorder, insolating layer
Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available



Specifications
Model KOV-600 KOV-720 KOV-1000 KOV-1800
Interior size (W*H*D)mm 1000*1000*600 900*1000*800 1000*1000*1000 1600*1400*600
Exterior size (W*H*D)mm 1360*1720*880 1300*1750*1000 1300*1750*1000 1600*1940*1200
Capacity(KVA) 6.5 7.5 8.5 9.5
Power AC 380V±10% 3Φ4wire 50Hz/60Hz
Temp. range 50 ºC~ 200 ºC( 300 ºC)
Temp. constancy ±1.0 ºC
Temp. uniformity ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
Heat up time 50 ºC to 200 ºC within 50 min
Interior material Stainless steel plate
Exterior material Painted Stainless steel plate
Insulation material Glass wool
Safety devices No fuse breaker, over temp protection, ceramic fuse
Accessories Recorder, insolating layer
Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations


Main technical specifications
Temp. fluctuation: ≤ ±0.5ºC
Temperature deviation: RT ~ +200 ºC ≤ ±2.0 ºC
+200 ºC~ +300 ºC ≤ ±3.0 ºC
Temp. constancy: ±1.0 ºC
Heat up time: 50 ºC to 200 ºC within 50 min
Control temperature means: Forced hot air circulation, ventlation mode
Interior material: Stainless Steel Plate
Exterior material: Baked painting steel


Features of portable small laboratory vacuum drying oven device:

1. Made of high quality coated stainless steel plate, processed with electrostatic powder spraying; the coat is hard and firm, with strong rust resistance.

2. The test space for the high quality matte stainless steel plate, round shape, easy to clean.

3. Between housing and inner steel plate, filled with rock wool and ceramic wool thermal insulation material, so the drying oven has good thermal insulation function, effectively guarantee high temperature bearing capacity and the accuracy of the stability of the temperature in the cabinet and the use of the environment.

4. The door is for multi-hollow glass structure, the material heated in the oven can be observed clearly, and have good heat insulation effect. Can effectively avoid burns operator.

5. Test space and equipped with heat resistant rubber sealing ring between the glass door, to ensure to achieve high vacuum degree in the box.

6. The outer surface of the heater is installed on the inner wall of the test area, to improve the uniformity of the temperature in the cabinet as much as possible, and to facilitate the room clean.

Temperature precision
For specific heat treatment processesand drying of protectiveheat sensitive materials, we havea precise answer.

Safety for high-risk heating
Where there‘s a risk of fire, explosionor the release of aggressivegases or vapors, we offer a safeoven solution.

Material-specific
There are high precise drying ovens specifically designed for materials testing,including cable testing ovens forrubber and plastics.

Space saving
A choice of built-in and bench topovens optimize your laboratoryspace.

Customized Products
We will work in partnership withyou to tailor-make your oven tomeet your particular specifications.

Competent advice
Explain your application need toour specialist and we will suggestthe right product.


Company information:
Being a first-class supplier and reliable partner, we are certified to ISO 9001 and got CE approval for all our products. All equipment are 7 x 24 hours tested before delivery. That explains why Komeg is the private brand of choice for many well-known brand enterprises, and also one of the very few designated suppliers who were recognized by many top 500 enterprises. Let Komeg's 26 years of professional experience work for you too.
