Water Cooled 100L Thermal Shock Test Chamber For Metal / Plastic / Rubber

Water Cooled 100L Thermal Shock Test Chamber For Metal / Plastic / Rubber
Water Cooled 100L Thermal Shock Test Chamber For Metal / Plastic / Rubber

Large Image :  Water Cooled 100L Thermal Shock Test Chamber For Metal / Plastic / Rubber

Product Details:
Place of Origin: China
Brand Name: KOMEG
Certification: CE, ISO9001
Model Number: TST-100A
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: negotiation
Packaging Details: Packed with film firstly, and then reinforced with wooden case for outer packing
Delivery Time: 35 days upon receive your first payment
Payment Terms: T/T, negotiable
Supply Ability: 1, 000 SETS / YEAR
Detailed Product Description
Application: Indoor, Lab, Testing Center In LED Industry Recovery Time: Exposure 30 Min
Conversion Time: 3 Min Internal Volume: 100L
Shock Temp. Range: -40ºC~+150ºC/ -70ºC~+150ºC Cooling Method: Water Cooled
High Light:

temperature shock test chamber

,

thermal shock chamber

100L 3 Zone Thermal Shock Test Temperature Cycling Chamber / Thermal Test Chambere



1. Application of thermal shock chamber


1.1 Application:



is used to test the bearing extent of the material structures and composite material in an instant and continuous high temperature and extremely low temperature environment , that is in the shortest time to test its thermal expansion and contraction caused by chemical change or physical harm. Application objects, including metal, plastic, rubber, electronics ... and other materials can be used as a basis to improve their products or reference.



1.2 ​Corresponding standard:

ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC


1.3

  1. Perfect appearance and easy to operate.
  2. Imported LCD English microcomputer temperature controller, with high memory capacity, can save 100 programs, max 9999 cycles, each cycle max time 999hrs.
  3. Two chamber structures, high temperature chamber and low temperature chamber, control automatically, stay and switch time adjustable.
  4. Perfect protection alarm functions: short-circuits, Leakage, over temperature of work chamber; compressor over pressure, over load, short water…
  5. Control interface will display alarm reason and provide check methods, machine has emergency stop button.
  6. Cold and hot shock temperature recover within1 minute, which complies with MTL, IEC, JIS, GJB and other international standards.

Water Cooled 100L Thermal Shock Test Chamber For Metal / Plastic / Rubber 0

2. More Info About KOMEG's Products You Need to Know



2.1 Refrigeration system characteristics

· The equipment is divided into high temperature zone, low temperature region, the three parts of the test area, the body of each zone by thermal unique structure.

· Can choose the starting position, high or low temperature cycling.

· Using color touch crystal display controller, simple operation, easy to learn.

· High formula memory capacity can be set to 120 patterns. The maximum cycle’s setting is 9999. The maximum setting time of each pattern is 9999Hrs 59 minutes.

· The machine is divided into three sections: the high temperature chamber, the low temperature chamber, and testing chamber.



2.2 Structure Features

Wall material:Top-grade Carbon Steel Plate,Surface electrostatic color Spray processing

Inner wall material:Stainless Steel Plate SUS304

Body insulation material:Rigid polyurethane Foam + glass fiber

Door insulation material:Rigid Polyurethane Foam + Glass fiber



2.3 Material:

Interior material: Stainless Steel Plate SUS304#

Exterior material: Baked Painting Steel Plate or Stainless Steel SUS304#

Insulation material: Rigid polyurethane Foam and Glass Fiber Wool



3. Why KOMEG Will Be Your Best Choice?



 The controller system features:

 Centralized controller, recorder, computer triad controller;

 1. Provide USB port, R485 interface, USB download;

 2. Large capacity may save 13450 segments, with super long running of 530 hours each segments.

 3. Program loop can be 32000 times, tiny loop 32000 times;

 4. Large built-in storage, can store 90 - day calendar data, historical curve (when the sample is 1 min)

 5. Support English, Chinese and so on.



4. Specifications



Model
Thermal shock test chamber TST-A Series
70A 130A 226A 360A 500A
Test weight(KG) 5 5 5 5 10
Interior size W(mm) 410 520 610 710 810
H(mm) 560 670 770 830 710
D(mm) 410 520 610 770 860
Basket size W(mm) 300 410 510 610 710
H(mm) 300 410 510 730 610
D(mm) 300 410 510 510 730
Low Temp. chamber  -55ºC~-10ºC
Pre-cooling time  +20ºC~-55ºC, Within 60 min
Test. chamber  -40ºC~+150ºC
High Temp. chamber  +60ºC~+200ºC
Pre-heating time  +60ºC~+200ºC ,Within 25 min
Recovery time High-Temp Exposure 30 min
Low-Temp Exposure 30 min
Recovery time within 3 min
Standard accessory Cable port(portΦ50mm)*1,   shelves*2
Interior material Stainless steel plate(SUS 304)
Exterior material Baked painting steel or stainless steel(SUS304)
Insulation material Rigid polyurethane Foam+glass fiber wool
Refrigeration system Water Cooled

Semi-hermetic compressor, cascade  refrigeration system,

CFC free refrigerant(HFC-507 and HFC-23)

Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model:Program or fix point running
Memory capacity:120programs,1200steps, all repeat 999cycles,part repeat 99 cycles.
Accuracy:Temp.:0.1% of F.S±1 digit                                                    Humidity:0.1% of F.S±1 digit
Input:Temp.:pt-100                Humidity:pt-100 or ~5V DCV
Ambient Temp. +5ºC~+35ºC
Power AC 380±10% 50Hz ,3 phase 4 wires +Ground Wires
Note:1. We reserve the right to change specifications without prior notice  2. Customized sizes and configurations available
