Industrial Vacuum Drying Oven Easy Operate With 5 Shelves / 4 Sided Heating

China KOMEG Technology Ind Co., Limited certification
China KOMEG Technology Ind Co., Limited certification
Fast delivery and quality products.

—— Gozia

Friendly and pleasant cooperator, "I like the factory, I like the design, I like the workstyle"

—— Wagner

The design and quality impress me a lot.

—— Mr Yee

" A trustworthy supplier of climatic test chamber".

—— Denis

I'm Online Chat Now

Industrial Vacuum Drying Oven Easy Operate With 5 Shelves / 4 Sided Heating

Industrial Vacuum Drying Oven Easy Operate With 5 Shelves / 4 Sided Heating
Industrial Vacuum Drying Oven Easy Operate With 5 Shelves / 4 Sided Heating

Large Image :  Industrial Vacuum Drying Oven Easy Operate With 5 Shelves / 4 Sided Heating

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: KOMEG
Certification: CE,UL
Model Number: KOV-1500

Payment & Shipping Terms:

Minimum Order Quantity: ONE SET
Price: USD3000-USD10000
Packaging Details: Strong Plywood Case, Meet International Standard
Delivery Time: 25-50 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 sets a year
Detailed Product Description
Usage: Universal Testing Machine Product Name: Vacuum Drying Equipment
Exterior Material: Stainless Steel Plate Standard: Standard And Customized
Temp. Range: 50º C-300º C Application: Widely
Power: AC 380V±10% 3Φ4wire 50Hz/60Hz Temp. Constancy: ±1.0 ºC
Timing Range: 1~9999 Min Chamber Material: Stainless Steel Liner
High Light:

vacuum drying oven

,

Industrial Drying Cabinet



Laboratory Industrial Vacuum Dry Oven with 5 Shelves and 4 Sided Heating





Application



Vacuum drying oven is widely used in biochemistry, chemical and pharmaceutical, health care, agricultural research, environment protection and other areas of research and application for powder drying, baking and all kinds of glass containers’ disinfection and sterilization. Especially for those drying heat-sensitive, labile, oxidizing material and decompounded to carry on fast and effective drying process.



Advantages of vacuum dry technology



Vacuum environment greatly lowered the liquid’s boiling point which needs to be driven away, therefore the vacuum dry method can be applied into heat sensitivity material. ·For the samples which can't be dried easily, such as powder or other pellet form sample, using vacuum dry method may effectively reduce drying time. ·Various complex structures of machinery ministry or other porous sample process use vacuum dry method after washing will not leave any residue; ·Safety guarantee: whether under vacuum or inertia condition, the possibility of oxide explodes when is heated will completely be eliminated. ·Compared with the normal drying method depended on air circulation, powder samples will not be blown or moved away by air







Features





1. Hot sales heated vacuum chamber price for specialty universities uses high quality cold-rolled steel plate, coated with electrostatic powder spraying; the coat is hard and firm, with strong rust resistance.


2. The studio is made up of high quality stainless steel plate,whitch has round shape and is smooth ,fluent and easy to clean.


3. Hot sales heated vacuum chamber price for specialty universities is full of superfine glass wool thermal insulation material between the box and the studio,what brings good heat preservation. That can effectively guarantee the stability and accuracy of the temperature in the box and the influence to the environment.


4.  Hot sales heated vacuum chamber price for specialty universities has a double-layer tempered glass door , users can observe items being heated inside the machine clearly and has good heat insulation effects. The operator can avoid being burned.


5. There is a rubber sealing ring between the studio and glass door to ensure the higher vacuum.


6. The heater is installed on the surface of the studio to improve the temperature uniformity as possible and easy to clean.


7. Temperature control adopts microcomputer intelligent digital technology manufacture, has industrial PID. It has four-digit double LED Windows indicating function, precision temperature control, strong anti-jamming ability, and is also very convenient to operate (see Temperature Controller Operating Manual).







Technical parameter





Specifications of drying oven
Model KOV-50 KOV-100 KOV-200 KOV-290 KOV-500
Interior size (W*H*D)mm 400*350*350 450*500*450 600*600*600 600*950*500 800*1050*600
Exterior size (W*H*D)mm 1010*650*760 1110*800*1100 1260*900*1100 870*1590*640 1160*1760*880
Capacity(KVA) 3.5 3.5 4.5 4.5 6
Power AC220V±10% 1Φ 50Hz/60Hz AC 380V±10% 3Φ4wire 50Hz/60Hz
Temp. range 50 ºC~ 200 ºC( 300 ºC)
Temp. constancy ±1.0 ºC
Temp. uniformity ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)
Heat up time 50 ºC to 200 ºC within 50 min
Interior material Stainless steel plate
Exterior material Painted Stainless steel plate
Insulation material Glass wool
Safety devices No fuse breaker, over temp protection, ceramic fuse
Accessories Recorder, insolating layer

Note:

1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available



specifications



Model



KOV-600 KOV-720 KOV-1000 KOV-1800
Interior size (W*H*D)mm 1000*1000*600 900*1000*800 1000*1000*1000 1600*1400*600
Exterior size (W*H*D)mm 1360*1720*880 1300*1750*1000 1300*1750*1000 1600*1940*1200
Capacity(KVA) 6.5 7.5 8.5

9.5



Power

AC 380V±10% 3Φ4wire 50Hz/60Hz



Temp. range

50 ºC~ 200 ºC( 300 ºC)



Temp. constancy

±1.0 ºC



Temp. uniformity

±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC)



Heat up time

50 ºC to 200 ºC within 50 min



Interior material

Stainless steel plate



Exterior material

Painted Stainless steel plate



Insulation material

Glass wool



Safety devices



No fuse breaker, over temp protection, ceramic fuse

Accessories



Recorder, insolating layer

Note:

1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations





Big Reasons to Buy



1. We appreciate you, the customer, and we always treat our customers with the greatest consideration and courtesy.


2. We'll be here tomorrow. Our business has been headquartered in Shenzhen, Dongguan for over twenty years. We are one of the largest independant environment test equipment manufacturers in China.

3. We'll do our best to remedy any problem you might have with a purchase. We are old fashioned in our customer service; We believe we have an obligation to give you our best if you purchase from us.

4. Your order will be filled accurately and shipped promptly. We have thousands of parts in stock. We have been selling by email order for over fifteen years.


5. You won't pay too much. Our volume buying and low overheads assures you of a low price and top quality new products.





Our Services





1,Pre-sales service



Before the purchase, our company will provide customers with detailed product-related information, and welcome you to visit the company and check the goods.



2,After-sales service



After the completion of the transaction, our company will be arranged different after-sales service according to the ease of the goods , and even arrange work engineers on-site service.



3,Warranty period



Our product warranty is 12 months and we are committed to responding within 48 hours of the problem, providing a solution.





Contact



If you are interest in our product and want to know more details about it, please kindly contact Bella Mo via e-mail bella@komegtech.com or our web www.komegtech.com . Welcome to enquire and visit us. ,we are honored to serve you.
