Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber

China Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber supplier
Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber supplier

Large Image :  Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber

Product Details:

Place of Origin: CHINA MAINLAND
Brand Name: KOMEG
Certification: CE CERTIFICATE
Model Number: HL-90-BS

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: 1100 ~6800 USD / SET
Packaging Details: Packed in carton firstly, and then reinforced with plywood case for outer packing
Delivery Time: 10 working days after received your payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 SETS PER YEAR
Contact Now
Detailed Product Description
Power: Electronic Temperature Range (Testing Space): 35±1℃~50±1℃
Testing Room Relative Humidity: > 85% Usage: Salt Spray Test Chamber
PH: 6.5~7.2; 3.0~3.2 Air Compressor: 1/2 HP
Power Supply: AC220V 50Hz Volume: 270L
Test Applicable: NSS, ACSS,CASS,CORK Package: Plywood


Composite Salt Fog Test Machine Hot and Humidity Test Chamber Environmental Test Chamber



Product Description



Salt spray test is an accelerated corrosion test that produces a corrosive attack to the coated samples in order to predict its suitability in use as a protective finish. The appearance of corrosion products (oxides) is evaluated after a period of time. Test duration depends on the corrosion resistance of the coating; the more corrosion resistant the coating is, the longer the period in testing without showing signs of corrosion. Different coatings have different behaviour in salt spray test and consequently, test duration will differ from one type of coating to another.


According to the standard parameter of JIS, ASTM, CNS, GB.


salt spray test: NSS, ACSS


test room:35℃±1℃

Air pressure barrels:47℃±1℃


Corrosion resistance test: CASS


test room:50℃±1℃

Air pressure barrels: 63℃±1℃





Specifications (Note: We reserve the right to change specifications without prior notice)






Interior dimensions(W*H*D)mm

1600 X 500 X 1000

1200 X 500 X 800

900 X 500 X 600

600 X 400 X 450

Exterior dimensions(W*H*D)mm

2240 X 1500 X 1600

1410 X 1280 X 880

1460 X 1280 X 910

1130 X 1070 X 630

Testspace Volume(L)





Salt Water Tank Volume (L)










Air compressor





Temp. range (Testing barrel)


Temp. range (Pressure barrel)


Test applicable


Pressed Air Pressure


Spray Amount

1.0~2.0ml/80cm²/h(Collect at least 16 hours, take the average)

Ambient Relative Humidity

More than 85%R.H.

PH Value

6.5~7.2 3.0~3.2

Spraying Manner

Programmable Spraying


AC220V 1Φ 50Hz




Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber




(1) Spray tower


(2) Funnel cup


(3) Touch screen controller


(4) Regulator


(5) Pressure gauge


(6) Metering cylinder



Controller(figure 2)


Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber


Controller instruction:


(1)Chamber real-time temperature


(2)Chamber temperature setting


(3)Actual test time


(4)Test time setting


(5)Accumulative time


(6)Power swithch


(7)Machine start/stop working button


(8)Spray start/pause button


(9)Test chamber low water alarm


(10)Defog after test


(11)Salt water tank low water alarm


(12)Reduce setting value


(13)Increase setting value


(14)Pressure barrel low water alarm


(15)Non-spray time setting


(16)Spray time setting


(17)Pressure barrel temperature setting


(18)Pressure barrel real-time temperature



Technical base


Box material The inside and outside the box are made of high temperature and high humidity corrosive high grade A gray PVC (thickness 5 ~ mm), the use of advanced production technology with three-dimensional ring, welded, solid structure, never deformation, gorgeous, applicable to salt spray, copper acetate and other testing specifications.
Reagent bottle Conceal one-piece reagent bottle, easy cleanout and operation.
Air pressure barrel It is made of SUS304 # stainless steel, refined tank structure design, high temperature, high humidity, high pressure, high corrosiveness resistant., and after several years of accumulated experience, successfully solved the short time water shortage of the general salt spray machine technical problems, unique internal design of the pressure tank, so that water shortage in pressure tank is no longer your worry and troubles. It is in a leading position in the industry.
Test sample holder A "gray" PVC material is refined into a "V" shaped strip. The full set is made of molds. The strength is higher. It is matched with tempered glass straight 10mm "O" strip to ensure that the product 15 ° -30 ° angle of the test sample rack using flat indexing, can adjust the angle, four fog uniform, consistent by the fog, the test results are accurate, the number of test samples placed more.
Chamber cover Using a 5mm thick transparent PVC plate with high toughness, a 100 degree ridge transparent cover was designed by physical bending method, so that dew droplets remaining on the cover slid along the cover wall to the sealing groove not fall the test products.
Other Function

A. With self-detection and other advanced features, is a great choice for your multiplier.

B. All-digital circuit design, accurate temperature control, use high-quality imported electrical materials, reasonable wiring design, long life, test function is complete.

C. With power outage memory function, so that the original time after the call to complete the remaining time to complete the test Inspection work, with double over-temperature protection, water level warning, to ensure safe use.

D. Spray and stop fog time can be set separately for circulating intermittent spray.

E. Fog seal tank using environmentally friendly water sealing, to prevent mist leakage.

F. Spray tower with conical disperser, with a guided fog, adjust the fog and even falling fog, etc.

G. The instrument adopts ergonomic design, beautiful appearance, easy operation.
Air supply system Air pressure is two-stage adjustment, the first is roughly adjustment 2 Kg/cm2, import air filter with the function of water draining, the second is accurate adjustment 1Kg/cm2,1/4 pressure gage, show precision and accuracy.
Mist spray pattern

Knut principle absorb the salt water and then atomization, fogging degree is on average, no block and crystal phenomenon absolutely, make sure the test proceed continuously.

  1. The nozzle makes of tempered glass, can be adjust the size and the angle of spray.
Spray quantity of 1~2ml/h can be adjustable (ml/80cm2/h test on the standard requirement average quantity of 16 hours). The hopper installs in cell, good looking and orderliness appearance, observe convenience, reduce the instrument install space.
Heating system Adopt direct heating way, fast rate of temperature increase so reduce the standby time, when reach the temperature, automatic shift temperature constant state, accuracy temperature, low power consumption. Pure titanium heating tube, resistance to acid and alkali corrosion, overlength working life.
Safety Protection Laboratory pressure saturation tank heating tank with liquid expansion safety temperature controller 0 ~ 120 ℃ (Italy EGO). Automatic, manual two water systems, automatic or manual pressure bucket, laboratory water level, to prevent water damage to ultra-high temperature instruments.



Illustration on the back of the salt spray tester



Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber


Composite Salt Fog Test Chamber , 270L Volume Hot And Humidity Test Chamber


Our Services


We are on line 24 hours, your any questions will get timely effective treatment and recovery.





Depending on the size of the order and its destination, we will find the most efficient way of delivering your order. Collect shipments through your account at UPS, FedEx, freight forwarder of choice or other can also be arranged. Let us know of such arrangements with your Purchase Order.

Quotes and Orders do not include customs duties and taxes as they vary from country to country and are the sole responsibility of the buyer.





1. Q: Have your machine met relevant standards, and with relevant TEST CERTIFICATE?


A: Yes, our machines are manufactured according to International Standards. If TEST CERTIFICAT required, it can be offered.


2. Q: How-to vedio provided?


A : Yes, if required, our engineers will record a specialize how-to video for you.


3. Q: Is the machine made in your own plant?


A: Yes, welcome to visit our plant(factory), also we support OEM and ODM.


4. Q:How you do the maintenance oversea?


A: In the way you are convenient, by Telephone or E-mail or Vedio meeting etc.



If you are interested in any item of our company, kindly please contact Bella via call at 0086-13532825374 directly or send your inquiy to bella@komegtech.com  for more information and fast response, welcome to visit us and look forward to serving your needs
