Product Details:
Payment & Shipping Terms:
|
| Temperature Range: | -70 ～ 150 ℃ | Temp Deviation: | ±2.0℃ |
|---|---|---|---|
| Workspace Volume: | IW 1500× IH 600 × ID 700 Mm | Exterior Size: | IW 3400× IH 1100× ID 1250mm |
| Temp Constancy: | ±0.5℃ | Temp Uniformity: | ±2.0℃ |
| High Light: | Mobile Temperature Humidity Test Chamber,SUS 304 Temperature Testing Equipment,Mobile Temperature Testing Equipment |
||
Temperature Humidity Test Chamber /Climatic Test Chamber For Mobile
Customer size are welcome
KOMEG Specification for KMH-1000S.pdf
KOMEG Specification for KMH-150R.pdf
Product Specifcation
| KMH series | |||||||||||||||
| Model | 150R | 225R | 408R | 800R | 1000R | 150L | 225L | 408L | 800L | 1000L | 225S | 408S | 800S | 1000S | |
| System | Balanced & Humidity Control System | ||||||||||||||
| Temp.Range | -20ºC~150ºC | -40 ºC~+150ºC | -70ºC~+150ºC | ||||||||||||
| Humidity Range | 20~98%R.H | ||||||||||||||
| Temp.constancy | ±0.5ºC | ||||||||||||||
| Humidity constancy | ±2.5%R.H | ||||||||||||||
| Temp.uniformity | ±2.0ºC | ||||||||||||||
| Humidity uniformity | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | ±3.0%R.H | ±5.0%R.H | |||||||||
| Heat up time | -20ºC~+100ºC Within 35 mins | -40ºC~+100ºC Within 45 mins | -70ºC~+100ºC Within 60 min | ||||||||||||
| Pull down time | +20ºC~-20ºC Within 45 mins | +20ºC~-40ºC Within 60 mins | +20ºC~-70ºC Within 75 mins | ||||||||||||
Interrior material(CM) |
W | 60 | 70 | 70 | 100 | 100 | 60 | 70 | 70 | 100 | 100 | 70 | 70 | 100 | 100 |
| H | 60 | 70 | 75 | 100 | 100 | 60 | 70 | 75 | 100 | 100 | 70 | 75 | 100 | 100 | |
| D | 46 | 48 | 80 | 800 | 100 | 46 | 48 | 80 | 800 | 100 | 48 | 80 | 800 | 100 | |
Exterrior material(CM) |
W | 88 | 98 | 98 | 128 | 128 | 100 | 100 | 110 | 150 | 150 | 100 | 110 | 150 | 150 |
| H | 173 | 189 | 194 | 216 | 216 | 160 | 175 | 185 | 200 | 200 | 175 | 185 | 200 | 200 | |
| D | 140 | 146 | 174 | 175 | 195 | 98 | 108 | 128 | 128 | 148 | 108 | 128 | 128 | 148 | |
| Interior material | Stainless Steel Plate(SUS 304) | ||||||||||||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||||||||||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||||||||||||
| Refrigeration system | Air Cooled( Water Cooled Type is option) | ||||||||||||||
| Hermetic compresssor, refrigeration system |
Hermetic Compressor,Cascsde Refrigeration CFC free refrigerant (HFC-507/HFC-23) |
||||||||||||||
| Controllor | LCD Toch panel,Chinese or English display selectabile Operation model /Program or fix point rinning Memory capacity ,120programs,1200steps,all repeat999cycles,part 99 cycless. |
PID Parameter 9set Accuracy /Temp.:0.1%of F.S±1 dight Input /Temp.:Pt-100/Humidity:Pt-100or1~5VDCV Comm.Port RS-232C or RS-485 (Software is option) |
|||||||||||||
| Safety Devices | No fuse breaker,over pressure,over heat and over current protectors for compressor,over temp.protector,over load protectorof fan,dry heat pr techto | ||||||||||||||
| Standard Accessories | Sightwindow*1,cable port(portΦ50mm)*1,shelves*2,chamberlamp*1,power cable 2m | ||||||||||||||
| Weight(Kg) | 240 | 280 | 400 | 500 | 580 | 250 | 300 | 420 | 530 | 600 | 330 | 450 | 550 | 650 | |
| Ambient Temp. | -5ºC~+35ºC | ||||||||||||||
| POEWR | AC 380±10% 50Hz 3 phase 4 wires+Groud Wires | ||||||||||||||
| Explosive pressure relief device |
when the pressure in the equipment or pipeline exceeds the safety valve pressure relief automatically open equipped with:Bursting disc,protective cover,sensor switch,exhaust fan function: a.When the test items in the box explode,there is a pressure release pipe b.Protect the test equipment from sudden air pressure damage c.Protecting people |
||||||||||||||
| Ventilator | When the pressure in the tank exceeds the pressure of the safety valve and opens the pressure relief valve,the exhaust fan is automatically turned on. | ||||||||||||||
Application
Applicable to environmental adaptability and reliability test in such industrial units as electronics, electrical
appliance, battery, plastics, food, paper product, vehicle, metal, chemistry, building material, research
institution, inspection and quarantine bureau, university etc..
Environmental test chamber Standard
GB-2423.1-2008(IEC68-2-1)Test A: Low Temperature Test
GB-2423.2-2008(IEC68-2-2)Test B: High Temperature Test
GJB360.8-2009(MIL-STD.202F)High Temperature Life Test
GBJl50. 3 (MIL-STD-810D) High Temperature Test
GJBl50. 4 (MIL-STD-810D) Low Temperature Test
Product details
Packing and Shipment:
After-sales Service and Training
Charge-free warranty will last for 1 year from the date of equipment acceptance. After the warranty
period, the user will be charged properly. Irregular examination and life-long service are available;
Note: If needed, provide 2 operators for on-site installation and training
A temperature and humidity chamber (also known as a climate or climate chamber) simulates the effect of a range of temperature and humidity conditions on a product or material, such as telecommunications equipment or photovoltaic solar panels exposed to outdoor temperature and humidity conditions. They have applications in as diverse industries as food science, semiconductors, and military quality assurance. A good constant temperature and humidity chamber is critical to assessing the potential success or failure of a product in the field. Climatic test chambers come in a variety of sizes, from small boxes that fit on a bench to room-sized chambers for large objects or testing large batches of products simultaneously. The temperature range is -73C to 190C, and the relative humidity range is 10% to 98%. Climate chambers are also used when product testing requires constant climatic conditions (temperature and/or humidity).
