Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved

China Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved supplier
Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved supplier Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved supplier

Large Image :  Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: KOEMG
Certification: CE ,ISO9001
Model Number: KMVH-1000S-C5

Payment & Shipping Terms:

Minimum Order Quantity: ONE SET
Price: Negotiation
Packaging Details: Strong plywood case
Delivery Time: Within 30 Workdays after receipt of the down payment
Payment Terms: L/C, T/T, MoneyGram, Western Union
Supply Ability: 100 Set/Sets per Month
Contact Now
Detailed Product Description
Temperature Range: -70℃ ~ +150℃ Humidity Range: 20%R.H~98%R.H
Chamber Size: Workspace Volume: W 1000 × H 1000 × D 1000 Mm Wall Material: High-quality Carbon Steel With Static Color Spray
Evaporator: Copper Aluminum Finned Evaporator Frequency Range: DC~3000 Hz
Max Displacement(p-p): 51mm Axial Vibration Isolation Frequency: 2.5 Hz
Surrounding Environment: Ensure Operating Environmental Temperature Range: 5〜35℃ Power Supply: AC 3ψ4W 380V 50Hz (R.S.T.N Ground Wire)( Voltage Fluctuation≦±10%)


Testing Chamber Temperature and Vibration Combined Climatic Test Chamber


Product Description


KOMEG has been focused on the latest development of the reliability test technology and attaches great importance to improve the reliability of test equipment. The requirements of environmental simulation also make customers realize the importance that one supplier provides the vibration systems and test chamber to realize the complete comprehensive test. .We can base on customer different test requirements, offers a broad range of integrated environmental testing systems, such as three integrated, four integrated test equipment solutions (air-cooled vibration test system with low-pressure test chamber), multi-axis vibration test system and test with the latest technology.


Main Technical Parameters


Temperature deviation ≦±2.0℃
Temperature fluctuation ±0.5℃
Temperature uniformity ≦2.0℃
Humidity deviation


Humidity fluctuation ±2.0%RH
Heater High-quality nickel-chromium alloy wire electric heater, non-contact control (SRR)
Compressor BOCK Semi-hermetic compressors
Display Resolution Temperature: + 0.01ºC; Humidity: + 0.1%; time: 1min
Cable port Φ50mm*1 located on both sides(each*1) with a rubber stopper and plastic cover
Temperature change rate

Heating rate: -70℃ to +150℃ nonlinear 5℃/min no load

Cooling rate: +150℃ to - 70℃ nonlinear 2℃/min no load


Rated Sine Force(peak) 20 kN
Max Velocity 2.0 m/s
Max Acceleration 1000m/s2
Body Size( No packing)(L×W×H) 1182mm×758mm×1052mm
Horizontal slide Table size (mm) 600×600 mm
Use Frequency (Hz) 2000 Hz
Fan power 7.5 kW
Wind pressure 3.5 kpa
Humidity 0~90% (No condensation)
One class resonant frequency 2500Hz±5%


Performance Feature

1. A Temperature Limit and alarm is included to protect your product.
2. Fog-free viewing window and interior light make viewing workspace hassle-free.
3. Humidity water filtration system to filter impurities and protect chamber interior.
4. An electronic humidity sensor is used on all humidity models for accuracy and minimal maintenance.


How do you attach the hardware you’re testing to your shaker?

By means of a fixture, usually aluminum or magnesium for lightness coupled with rigidity. They can be cast, or smaller fixtures machined from solid stock. Most fixtures are welded.

How do you control shakers?

If we’re looking for resonances in the product we’re testing, we command the shaker to shake the product at one frequency at a time but to vary that test frequency, to sweep it over a range of frequencies. But more realistically, we command the shaker to vibrate randomly and to excite all the resonances simultaneously. Control commands go into the keyboard of a specially-programmed computer.

What are those resonances?Are they bad?

Have you ever noticed the steering wheel moving with rather a large displacement amplitude, larger than the input to the column? That magnification is called resonance. Possibly it annoys you. There’s a slight chance that in a few years that whipping of the steering column might cause bending fatigue failure. When we shake an automotive or ship or land vehicle instrument, we're looking for, for example, portions of printed wiring boards (PWBs) responding with greater motion than we're inputting. That flexing may damage PWB wiring, it may damage the attached components, and it will damage the soldered connections between components and the PWB.



Pre-sales service

1) More than 20 years of manufacturer experience and 8 years of export experience.
2) Acceptable customization for all kinds of special specification products.
3) We value every inquiry sent to us, ensure quick and competitive offer.
4) We put your order into our tight production schedule, ensure your punctual delivery time.
5) We are a sales team, with more than 4 years of experience, more professional and reliable.
6) Welcome to view our factory at any moment.

After-sales service

1) We deal with your complaints within 24 hours.
2) Training how to install the machine, training how to use the machine.
3) Engineers available to service machinery overseas.
4) All staff in our company with a philosophy of " integrity, dedication, truth-seeking, enterprise", would be dedicated to providing high-quality service and products for you.





Q: What's the delivery term?


A: It depends on the machine's dimensions and weight, also according to the customer's requirement. It could be shipped by sea, by air or by air express. Usually, the delivery time is about 15-20 working days after receipt of down payment. If you are in urgent need, we can make a special arrangement for you.


Q: What’s the payment term?


A: T/T, L/C, and other payment terms could be negotiated.


Q: What's the warranty and after-sales service?


A: We provide free parts warranty for 12 months. Feedback to you within 24 hours and help you to repair your problem controller freely, even it's not from our factory.


Q: Do you accept customization service?


A: Yes, the inner chamber dimensions can be customized as per your specific request.Temperature And Vibration Combined Climatic Test Chamber CE / ISO 9001 Approved
