Product Details:
Payment & Shipping Terms:
|
| Volume: | 225L | Temperature Range: | -40 °C To 150/180 °C |
|---|---|---|---|
| Material: | SUS304 Stainless Steel | Controller: | LED Touchscreen 7 Inch |
| Humidity Uniformity: | ±3.0% Or ±5.0% | Humidity Range: | 10~98% |
| High Light: | Climatic Testing Chamber,Environmental Test Chamber |
||
Climatic Test Chamber, Temperature Humidity Environmental Test Chamber
GB11158 Technical conditions for high-temperature testing box
GB10589-89 Technical conditions for low-temperature testing box
GB10592-89 Technical conditions for high and low temperature testing box
B/T10586-89 technical conditions for humidity testing chamber
GB/T2423.1-2001 Low-temperature testing methods
GB/T2423.2-2001 High-temperature testing methods
B/T2423.3-93 Testing Method for humidity Test Chamber
GB/T2423.4-93 Alternating hot and humid testing method
GB/T2423.22-2001temperature testing method
IEC60068-2-1.1990 low-temperature testing method
IEC60068-2-2.1974 high-temperature testing method
GJB150.3 high-temperature testing
GJB150.4 low-temperature testing
GJB150.9 humid testing
KMH-L series
| Model | KMH series | |||||
| 150 L | 225 L | 408 L | 800 L | 1000 L | ||
| Temp. range | -20°C ~180°C, -40°C ~180°C, -70°C ~180°C for option | |||||
| Interior size | W(mm) | 600 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | |
| Weight(KG) | 250 | 300 | 420 | 530 | 600 | |
| Temp. uniformity | ±2.0ºC | |||||
| Heat up time | -40°C ~+100°C ,within 45 min | |||||
| Pull down time | +20°C ~-40°C , within 60 min | |||||
| Humidity Range | 10~98%R.H | |||||
| Temp. constancy | ±0.5ºC | |||||
| Humidity constancy | ±2.5%R.H | |||||
| Humidity uniformity | ±3.0%R.H or ±5.0%R.H | |||||
| Safety device (standard) | NFB, over pressure,over heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection | |||||
| Warranty | 12 months basiclly, and 24 months for choose | |||||
| Interior material | Stainless Steel Plate(SUS 304) | |||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |||||
| Ambient Temp. | +5°C ~+35°C | |||||
| Wiring method | AC 380±10% 50Hz ,3 phase 4 wires +Ground Wires | |||||
| Controller | LCD Touch Screen, Chinese or English display selectable | |||||
| Operation model :Program or fix point running | ||||||
| Memory capacity :120programs,1200steps, | ||||||
| All repeat 999 cycles, part repeat 99 cycles |
||||||
5.Parts and brands
6.Trade show:
7. Package
Programmable Temperature & humidity testing Chamber
Air Thermal Shock Tester
Thermal Shock Tester
Rapid temperature change chamber/ ESS
Salt Spray Tester
Walk In environmental Testing Chamber
Drive in environmental Testing Chamber
Temperature & humidity & Vibration Combined Testing Chamber
Aging Oven Tester
Rain/Spray Testing Chamber
Burn-in testing equipment
Vibration Tester
Precision Oven Tester, etc.
