Product Details:
Payment & Shipping Terms:
|
| Application: | Laboratory, Testing Center, Production Line | Internal Volume: | 150L |
|---|---|---|---|
| Interior Material: | SUS 304 Stainless Steel Plate | Exterior Material: | Baked Painting Steel Or Stainless Steel |
| Warranty: | 12 Months Free Parts Warranty | Lead Time: | 60 Working Days Upon The Deposit |
| Trade Terms: | EXW, FOB, CIF, DDU, DDP | H.S. Code: | 9032100000 |
| High Light: | temperature and humidity chamber,humidity and temperature controlled chamber |
||
Lab use temperature humidity test chamber stability chambers environment and vibration test chamber
KMH-150L Temperature Humidity and Vibration three integrated Test Chamber
Environmental test chamber is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance. They are able to perform test under extreme conditions, variable temperatures and humidity environmentals ensuring high performance testing and superior quality of products. It is suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.
300kg.f~5000kg.f exciting force Vibration Temperature Humidity Combined Reliability Test Chamber Features
1,Independent control system: Realize the high temperature, low temperature, constant temperature and humidity, vibration test or a comprehensive test
2,Adopt moving orbit design, easily realize the comprehensive test or a single test requirements.
3.Our vibration test systems can match the different brands in the domestic and overseas chamber. Labtone is responsible for the assembly, to provide customers with a variety of specifications and performance of integrated environmental testing systems.
300kg.f~5000kg.f exciting force Vibration Temperature Humidity Combined Reliability Test Chamber Specifications
Main enviromental: Humidity, Temprature, Vibration
Vibration exciting force: 300kg.f~5000kg.f
Chamber dimension(inside):500*750*600mm 600*850*800mm
1000*1000*800mm 1000*1000*1000mm
Temprature range: -70~ +150℃(Max.)
Humidity range:20~98%R.H(Max.)
Vibration testing type:Sinusoidal vibration, random vibration, classical impact,resonance search and reside,sine-on-random
Any special requirement please feel free to contact us and we will try to realize it.
|
Model |
KMH-36L(Benchtop) | KMH-64 series | |||
| 64 R | 64 L | 64 S | |||
| Temp. range | -40°C ～150°C | -20°C ～150°C | -40°C ～150°C | -70°C ～150°C | |
| Interior size | W(mm) | 300 | 400 | 400 | 400 |
| H(mm) | 400 | 400 | 400 | 400 | |
| D(mm) | 300 | 400 | 400 | 400 | |
| Exterior size | W(mm) | 460 | 600 | 600 | 600 |
| H(mm) | 780 | 1526 | 1526 | 1526 | |
| D(mm) | 1002 | 1200 | 1200 | 1200 | |
| Power(KW) | 5.8 | 5.8 | 5.8 | ||
| Weight(KG) | 300 | 300 | 300 | ||
(1) KMH-R series
| Model | KMH-R series | |||||
| 150R | 225R | 408R | 800R | 1000R | ||
| Temp. range | -20°C ～150°C | |||||
| Interior size | W(mm) | 600 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | |
| Weight(KG) | 240 | 280 | 400 | 500 | 580 | |
| Humidity uniformity | ±3.0％R.H | ±5.0％R.H | ||||
| Heat up time | -20°C ～+100°C ,within 35 min | |||||
| Pull down time | +20°C ～-20°C , within 45 min | |||||
| Humidity Range | 20～98％R.H | |||||
| Temp. constancy | ±0.5ºC | |||||
| Humidity constancy | ±2.5％R.H | |||||
| Temp. uniformity | ±2.0ºC | |||||
| Safety device (standard) | NFB, over pressure,over heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection | |||||
| Interior material | Stainless Steel Plate(SUS 304) | |||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |||||
| Ambient Temp. | +5°C ～+35°C | |||||
| Wiring method | AC 380±10％ 50Hz ,3 phase 4 wires +Ground Wires | |||||
| Controller | LCD Touch Screen, Chinese or English display selectable | |||||
| Operation model :Program or fix point running | ||||||
| Memory capacity :120programs,1200steps, | ||||||
| All repeat 999 cycles, part repeat 99 cycles | ||||||
(2)KMH-L series
| Model | KMH-L series | |||||
| 150 L | 225 L | 408 L | 800 L | 1000 L | ||
| Temp. range | -40°C ～150°C | |||||
| Interior size | W(mm) | 600 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | |
| Weight(KG) | 250 | 300 | 420 | 530 | 600 | |
| Humidity uniformity | ±3.0％R.H | ±5.0％R.H | ||||
| Heat up time | -40°C ～+100°C ,within 45 min | |||||
| Pull down time | +20°C ～-40°C , within 60 min | |||||
| Humidity Range | 20～98％R.H | |||||
| Temp. constancy | ±0.5ºC | |||||
| Humidity constancy | ±2.5％R.H | |||||
| Temp. uniformity | ±2.0ºC | |||||
| Safety device (standard) | NFB, over pressure,over heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection | |||||
| Interior material | Stainless Steel Plate(SUS 304) | |||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |||||
| Ambient Temp. | +5°C ～+35°C | |||||
| Wiring method | AC 380±10％ 50Hz ,3 phase 4 wires +Ground Wires | |||||
| Controller | LCD Touch Screen, Chinese or English display selectable | |||||
| Operation model :Program or fix point running | ||||||
| Memory capacity :120programs,1200steps, | ||||||
| All repeat 999 cycles, part repeat 99 cycles | ||||||
(3)KMH-S series
| Model | KMH-S series | |||||
| 150S | 225S | 408S | 800S | 1000S | ||
| Temp. range | -70°C ～150°C | |||||
| Interior sizel | W(mm) | 600 | 700 | 700 | 1000 | 1000 |
| H(mm) | 600 | 700 | 750 | 1000 | 1000 | |
| D(mm) | 460 | 480 | 800 | 800 | 1000 | |
| Exterior size | W(mm) | 880 | 980 | 980 | 1280 | 1280 |
| H(mm) | 1730 | 1890 | 1940 | 2160 | 2160 | |
| D(mm) | 1400 | 1460 | 1740 | 1750 | 1950 | |
| Power(KW) | 5.8 | 6 | 7.5 | 12.8 | 12.8 | |
| Weight(KG) | 280 | 330 | 450 | 550 | 650 | |
| Humidity uniformity | ±3.0％R.H | ±5.0％R.H | ||||
| Heat up time | -70°C ～+100°C ,within 60 min | |||||
| Pull down time | +20°C ～-70°C , within 80 min | |||||
| Humidity Range | 20～98％R.H | |||||
| Temp. constancy | ±0.5ºC | |||||
| Humidity constancy | ±2.5％R.H | |||||
| Temp. uniformity | ±2.0ºC | |||||
| Safety device (standard) | NFB, over pressure,over heat and over current protection for compressor, Over temp. protect, over load protect of blower, dry heat protection | |||||
| Interior material | Stainless Steel Plate(SUS 304) | |||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |||||
| Ambient Temp. | +5°C ～+35°C | |||||
| Wiring method | AC 380±10％ 50Hz ,3 phase 4 wires +Ground Wires | |||||
| Controller | LCD Touch Screen, Chinese or English display selectable | |||||
| Operation model :Program or fix point running | ||||||
| Memory capacity :120programs,1200steps, | ||||||
| All repeat 999 cycles, part repeat 99 cycles | ||||||
1. Programmable setup is available, max 120 sets, 1200 segments and 999 cycles.
2. The refrigeration units are supplied by Tecumseh(France).
3. A large TEMI 1500 LCD touch screen controller helps to perform operations more conveniently.
4. A test graph indicator provides a continuous performance progress report.
5. A P.l.D auto counter enables continuous immediate temperature and humidity error correction.
6. A microprocessor control unit enables temperature and humidity fluctuation to be applied dividedly.
7. An OD 5 cm port is centered on the left side of the chamber for ease of cable routing.
8. Mist-free viewing window and interior light provide a hassle free viewing workspace.
9. Swivel casters provide easy mobility and flexibility in a variety of laboratory conditions.
10. Four-tiered safety protection system.
● GB-2423. 1-89 (IEC68-2-1)Test A: Low Temperature Test
● GB-2423. 2-89 (IEC68-2-2)Test B: High Temperature Test
● GJB360. 8-87 (MIL-STD. 202F) High Temperature Life Test
● GBJl50. 3 (MIL-STD-810D) High Temperature Test
● GJBl50. 4 (MIL-STD-810D) Low Temperature Test
● GB2423. 3-93 (IEC68-2-3)Test Ca: Constant Heat Test
● GB2423. 4-93 (IEC68-2—30)Test Db: Damp Heat Alternative Test
● GJBl50. 9-93 (MIL-STD-810D) Damp Heat Test
We use standard inner box PP film and carton plywood for the packing.
