High And Low Temperature Test Chambert / Environmental Temperature Test Climatic Chamber

China High And Low Temperature Test Chambert / Environmental Temperature Test Climatic Chamber supplier
High And Low Temperature Test Chambert / Environmental Temperature Test Climatic Chamber supplier High And Low Temperature Test Chambert / Environmental Temperature Test Climatic Chamber supplier

Large Image :  High And Low Temperature Test Chambert / Environmental Temperature Test Climatic Chamber

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: KOMEG
Certification: CE, ISO
Model Number: KMH-1000L

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: 10000-50000USD PER SET
Packaging Details: Packed with film firstly, and then reinforced with wooden case for outer packing
Delivery Time: 25 days upon your deposit
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1, 000 SETS / YEAR
Contact Now
Detailed Product Description
Usage: Temperature Change Test Chamber Insulation Material: Rigid Polyurethane Foam And Glass Fiber Wool
Cooling Mode: Water Cooled Heater: Iron-chrome Wire Heater
Controllor: Touch Screen Programmable Controller Temperature Range: -40 °C To 150 °C
Material: SUS304 Stainless Steel Power Supply: AC 380V±10% 50Hz ,3 Phase 4 Wires +Ground Wires
Exterior Material: Baked Painting Steel Workspace Volume (W X H X D): 1000*1000*1000mm



High low temperature test chamber equipment/environmental temperature test climatic chamber/control temperature cabinet





 General description:



Product Description


Temperature chamber models designed to save lab space

The Standard temperature chamber series provides an economical and space-saving solution for a variety of temperature testing requirements.

Lowest temperature: -20 or -70°C (-4 or -100°F)

Highest temperature: 180°C (354°F)

The extended temperature ranges of the Standard series make testing at extreme conditions possible without buying a larger, stand-alone chamber. Two chamber sizes are available, as well.

The programmer includes a temperature alarm as just one part of Grande's three-tiered over-temperature protection system. A thermal fuse and a user-set independent limit are also included. In addition, a specimen power terminal allows the user to safely operate powered equipment inside or with the chamber.





Main features:



1. LCD touch screen display controller. A lighted Controlpad displays the operating mode.



2. Optimal network: Using interface and web server the authorized user can reach current tests via the internet.



3. Test Data, reports, etc. can be managed in the network and the software Simpati can connect and utilize tests.



4. Security, comfort and performance: This chamber is able to maintain demanding climate values also under considerable strain, eg, by midsummer-like ambient temperatures.



5. Reduced upkeep and maintenance costs: Humidity bath purging prevents contamination of humidifier water - cleaning intervals become much longer.



6. The large water tank allows independent operation for several days - even longer test can be realized through an automatic feeding of additional water without interruption.



7. The optimum air flow in combination with an auto-adaptive control system ensures a very homogenous temperature distribution in the test space.



8. The control unit has the functions of multiples segment program editing, and with a temperature ramp



9. Temperature heating and cooling rate are from 3°C/min to 15°C/min, as per your specific request.




Parameter Specifications



KMH-R series

Model KMH-R series
150R 225R 408R 800R 1000R
Temp. range -20°C ~150°C
Interior size W(mm) 600 700 700 1000 1000
H(mm) 600 700 750 1000 1000
D(mm) 460 480 800 800 1000
Exterior size W(mm) 880 980 980 1280 1280
H(mm) 1730 1890 1940 2160 2160
D(mm) 1400 1460 1740 1750 1950
Power(KW) 5.8 6 7.5 12.8 12.8
Weight(KG) 240 280 400 500 580
Humidity uniformity ±3.0%R.H ±5.0%R.H
Heat up time -20°C ~+100°C , within 35 min
Pull downtime +20°C ~-20°C , within 45 min
Humidity Range 20~98%R.H
Temp. constancy ±0.5ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0ºC
The safety device (standard) NFB, overpressure,overheat and overcurrent protection for a compressor, Over temp. protect, over load protect of the blower, dry heat protection
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid Polyurethane Foam and Glass Fiber Wool
Ambient Temp. +5°C ~+35°C
Wiring method AC 380±10% 50Hz, 3 phase 4 wires +Ground Wires
Controller LCD Touch Screen, Chinese or English display selectable
Operation model: Program or fixpoint running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles





Specifications ( at +20℃ room temp. Or+25℃ water temp with empty load)
Model KMH-L series
KMH-150L KMH-225L KMH-408L KMH-800L KMH-1000L
Interior material(cm) 60*60*46 70*70*48 70*75*80 100*100*80 100*100*100
Exterior material(cm) 88*173*140 98*189*146 98*194*174 128*216*175 128*216*195
Weight(Kg) 250 300 420 530 600
Equipment power(KW) 7.5 7.5 8.5 14.5 14.5
Temperature range -40 ℃ ~ +150 ℃
Humidity range 20 ~ 98%R.H
Temperature constancy ±0.5℃
Humidity constancy ±2.5% R.H
Temperature uniformity ±2.0 ℃
Humidity uniformity ±3.0% R.H(>75%) ±5.0% R.H (≤75%)
Heating rate -40℃~+100℃ Within 45 minutes
Cooling rate +20℃~-40℃ Within 60 minutes
Controller Touch screen controller English menu Operation mode: setting or program
Refrigeration system Air cooled (Water Cooled Type is the option)
Hermetic compressor, stage refrigeration system
Interior material Stainless Steel Plate ( SUS 304 )
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid Polyurethane Foam and Glass Fiber Wool
System Balanced & Humidity Control System
Wiring method AC 380±10 % 50Hz, 3 phase 4 wires +Ground Wires
Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available



Technical parameters:
Environmental Temperature and Humidity Chamber
Specifications ( at +20°C room temp. Or+25°C water temp with empty load)
Model KMH-S series
225S 408S 800S 1000S
Interior sizel W(mm) 700 700 1000 1000
H(mm) 700 750 1000 1000
D(mm) 480 800 800 1000
Exterior size W(mm) 980 980 1280 1280
H(mm) 1890 1940 2160 2160
D(mm) 1460 1740 1750 1950
Weight(KG) 330 450 550 650
Temp. range -70 °C ~+150°C
Humidity Range 20 ~ 98&R.H.
Temp. constancy ±0.5ºC
Humidity constancy ±2.5%R.H
Humidity uniformity ±3.0%R.H ±5.0 % R.H
Heat up time -70°C ~ +100°C , within 60 min
Pull downtime +20°C ~ -70°C , within 80 min
Equipment Power 9.5KW 10.6KW 18.5KW 18.5KW
Ambient Temp. 5ºC ~+35ºC
Standard accessories Sight window*1, cable port(port 50mm)*1, shelves*2, chamber lamp*1, power cable *2m
The safety device (standard) No fuse breaker, overpressure over heat and overcurrent protection for the compressor,
Over temp. protect, overload protect of the blower, dry heat protection
Control System Balanced Temperature & Humidity Control System
Refrigeration system Air Cooled (Water Cooled Type is the option)
Hermetic compressor, Cascade Refrigeration
CFC-Free refrigerant(HFC-507/HFC-23)
Controller Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model : Program or fixpoint running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles
Interior material Stainless Steel Plate ( SUS 304 )
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid Polyurethane Foam and Glass Fiber Wool
System Balanced & Humidity Control System
Wiring method AC 380±10 % 50Hz, 3 phase 4 wires +Ground Wires
Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available





Company information



Being a first-class supplier and reliable partner, we are certified to ISO 9001 and got CE approval for all our products. All equipment is 7 x 24 hours tested before delivery. That explains why Komeg is the private brand of choice for many well-known brand enterprises, and also one of the very few designated suppliers who was recognized by many top 500 enterprises. Let Komeg's 26 years of professional experience work for you too.

1. Dedicate touch and excellent user experience
2. Unique and compact design, top-grade appearance, stable performance and easy operation
3. Can simulate a wide range of temperature and humidity environments
4. Capable of testing large components, assemblies and finished products
5. Customized sizes and configurations available
6. One year warranties





Besides this, we have a lot of other chambers for your reference:



3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine( mechanical and electromagnetic)





FAQ





Q1: What is the Warranty for the accelerated aging machine?



A1: For the accelerated aging machine, we offer 1 year warranty service. If any quality problems on our side occurred in this period, we will send you the replacement and cover the cost of shipping and component parts.



Q2: What's the delivery term?



A2: Usually, it takes us 20 - 25 days after order confirmation to produce the equipment and a little bit longer for customization service. While if you are in urgent need, we can make special arrangement to speed up the proceedings. Then we start the shipped by sea, by air freight or by air express.



Q3: What’s the payment term?



A3: T/T, L/C and other payment terms could be negotiated.



Q4: Is it ok for the customization service?



A4: Yes, the inner chamber dimensions, structure, color, some special parameters can be customized as per your specific request.
