Payment & Shipping Terms:
|Usage:||Universal Testing Machine||Type:||Air-ventilatiion Testing Machine|
|Controller:||LCD Touch Panel Controller||Insulation:||PU&Fiberglass Wool|
|Service:||Customization||Air Change Rate:||5 To 200 (3 To 250) Times/ Hour|
|Warranty:||12 Months||Temp. Range:||Room Temp. +20～+100℃|
|Power:||AC 380±10%50Hz ,3 Phase 4 Wires +Ground Wires||Interior Material:||Stainless Steel Plate(SUS 304)|
LCD Touch Panel Controller Analysis Instruments For Auto Ventilation Aging Test Chamber
Ventilation aging test machine used to test the rubber specimen wires, cables, insulation or covered, the aging of the sample to compare before and after aging of tensile strength and elongation. Ventilation aging chamber with hot air circulation, promote aging, confined within the box strong, with a removable inner box air apparatus, with over-temperature protection device automatically cut off.
Suitable for all kinds of electronic products,expecially for products with heating characteristics
Product and loading area should be separated
|Interior dimensions(W*H*D) mm||1500*1280*550|
|Exterior dimensions(W*H*D) mm||1720*1980*750|
|Temp. range||Room Temp. +20～+100℃|
|Test. capacity||88PCS/CYCLE(Custom made available)|
|Test range||FAN(full machines number)|
|The detection speed||7-12sec/cycle|
|Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
1. Standard combined design.
2. SUS#304 stainless steel,firm structure, waterproof design.
3. Suitable for test with large quantity and volume products.
4. Adopt imported large LCD Chinese/English microcomputer temperature controller, easy setting, strong function.
5. Standard RS-232C communication interface device.
6. Unique circulation duct design.
7. Comprehensive security control design, adopt intelligent PID+SST/SCR inverse two-way synchronous output,including the slope of the advanced control logic.
8. Heating box and explosion-proof heater design, advanced PID servo control, security, stability and reliability.
You are warmly welcomed to KOMEG.
We hope to be your reliable business partner in China.
For our new design can achieve high temp. Unifornity (± 0.5 C ).
Tecumseh or Danfoss compressor for your alternative choice.
Germany imported wall material make sure the reliability and good performace.
1. Empty burn prevent protection
2. Overtemperature protection
3. Circulating fan overload protection
4. Exhaust fan overload protection
5. Circuit breaker
6. No fuse switch
7. Phase sequence protection
Programmable Temperature & humidity testing Chamber
Triple layer Type Temperature & humidity Chamber
Temperature & humidity Control Host
Air Thermal Shock Tester
Liquid Thermal Shock Tester
Salt Spray Tester
Walk In environmental Testing Room
Temperature & humidity & Vibration Combined Testing Chamber
Aging Oven Tester
Rain/Spray Testing Chamber
Burn-in testing equipment, Dust Tester
Steam Aging Tester, Dispensing Robots
Electromagnetic High Frequency Vibration Tester
Tensile Tester, Drop Tester, Precision Oven Tester, etc.
Q1: What is the Warranty?
Generally, 12 months warranty. But for drying oven, the warranty is 18 months. If any quality problems on our side occured in this period ,we will take on the cost of shipping and component parts.
Q2: What's the delivery term?
Usually, 20 - 25 days after order confirmation. It will be took more time for customization service. If you are in urgent need, we can make special arrangement for you. It could be shipped by sea, by air or by air express.
Q3: What’s the payment term?
Accept different kinds of payment terms, such T/T, L/C, Paypal.
Q4: Is it ok for customization service?
Of course you can. We are manufacturer of environmental test equipment. Once with your detailed requests, we could make environmental test chamber accordingly.
