Product Details:
Payment & Shipping Terms:
|
| Product Name: | Ozone Chamber | Test Space(D*W*H）: | 500×500×600mm |
|---|---|---|---|
| Temperature Range: | 0℃～65℃ | Controller: | 7 Inch Touch Screen |
| Controllor: | Touch Screen Programmable Controller | External Dimension: | Depend On Design |
| Compressor: | French Tecumseh | Power Supply: | AC 380V±10％ 50Hz ,3 Phase 4 Wires +Ground Wires |
| Exterior Material: | Baked Painting Steel | Model: | QL-150 |
| High Light: | accelerated aging chamber,climatic test chambers |
||
Ozone Aging Testing Machine / Chamber / Oven / Cabinet / Equipment Air Exchange Type
Applications:
This instrument is available for rubber products,such as:vulcanized rubber,thermoplastic rubber,cable insulation sleeve.,etc. Have testing specimen to do the static stretching,or continuous dynamic stretching,or alternant static stretching and dynamic stretching;Put the testing specimen into the chamber.of which no light, containing a constant concentration of air.constant temperature.To do the testing per the pre-setting up time.The quality of rubber can be evaluated by inspecting the changing performance of the surface of testing specimen.
Main features:
Ozone endurance test chamber Equiped by the occurrence of silent and efficient ozone generator ozone gas, and a certain amount of air processed, the switch in the mixture into the chamber, the continuous line UV detector to detect the concentration of ozone, ozone generator control feedback to the systems to control system settings according to the occurrence of effective control of ozone to the ozone chamber to maintain the appropriate concentration of work by heating humidification systems to meet all the test conditions.
Parameter Specifications
| Test size | 500×500×600 |
| Temperature Range | 0～65℃ |
| Temperature Constancy | ±0.5℃ |
| Temperature deviation | ≤2℃ |
| Humidity range | ≥65%R.H |
| Heating rate | 3℃≤1min(customizable) |
| Cooling rate | 0.7～1.0℃/1min(customizable) |
| Ozone concentration | 25～250pphm(adjustable) |
| Ozone Deviation | ≤10%(national standard) |
| Rotation speed of the rack | 2～10r/min |
| Test gas flow rate | 20～70L/min |
| Power | 380V 50/60HZ |
| Temperature Accuracy | ±0.1℃ |
| Display resolution | Time:0.1min,temperature:0.1℃,humidity: 0.1%RH |
| Product Weight | 200kg |
| Control instrument | Adopt U-700 controller |
| Compressor | Original French Tecumseh compressor |
| Cooling mode | air cooled |
| expansion valve | Danfoss thermal expansion valve is designed for refrigeration applications |
| Small relays | Imported Omron small relays |
| AC contactor | France imported Schneider AC contactor |
| solid state relay | Switzerland solid state relays |
| breaker | Using the French Schneider circuit breaker |
| Over-temperature protection | Using domestic over-temperature protection |
| Temperature and humidity sensor | Taiwan Yifan PI100 sensors |
| Display language | Chinese / English switchable |
| Danfoss dry filter features | 80% 3A |
| Control range | 0～200PPm |
| Control accuracy | ±0.1PPm |
| Temperature sensor | PT100 |
Ozone test can be done static stretching and dynamic stretching:, Stretching testing of the sample itself is about 5% -45%;
Sample rack can be rotated 360 degrees, the indoor sample rack, fixtures and pipes and other accessories are adopt stainless steel and other materials not easily decomposed by ozone, and not have the impact of ozone concentration.
Company information
Being a first-class supplier and reliable partner, we are certified to ISO 9001 and got CE approval for all our products. All equipment are 7 x 24 hours tested before delivery. That explains why Komeg is the private brand of choice for many well-known brand enterprises, and also one of the very few designated suppliers who were recognized by many top 500 enterprises. Let Komeg's 26 years of professional experience work for you too.
1. Dedicate touch and excellent user experience
2. Unique and compact design, top grade appearance, stable performance and easy operation
3. Can simulate a wide range of temperature and humidity environments
4. Capable of testing large components, assemblies and finished products
5. Customized sizes and configurations available
6. One year warranties
Besides this, we have a lot of other chamber for your reference:
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Vibration Testing Machine( mechanical and electromagnetic)
FAQ
Q1: What is the Warranty for the accelerated aging machine ?
A1: For the accelerated aging machine, we offer 1 years warranty service. If any quality problems on our side occured in this period ,we will send you replacement and cover the cost of shipping and component parts.
Q2: What's the delivery term?
A2: Usually, it takes us 20 - 25 days after order confirmation to produce the equipment and a little bit longer for customization service. While if you are in urgent need, we can make special arrangement to speed up the proceedings. Then we start the shipped by sea, by air freight or by air express.
Q3:What’s the payment term?
A3: T/T, L/C and other payment terms could be negotiated.
Q4:Is it ok for customization service?
A4: Yes, the inner chamber dimensions, structure, color, some special parameters can be customized as per your specific request.
