Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen

China Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen supplier
Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen supplier Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen supplier

Large Image :  Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: KOMEG
Certification: CE ,ISO9001
Model Number: KM-XD-720

Payment & Shipping Terms:

Minimum Order Quantity: one set
Price: USD 13000~45000 PER SET
Packaging Details: Xenon Lamp Climatic Aging Test Chamber is packed by standard export wooden case
Delivery Time: 35-45 workday
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 Set/Sets per Month
Contact Now
Detailed Product Description
Humidity Range: 50% To 98%RH Xenon Arc Test Machine Test Size: H 800 × W 800 × D 800mm
External Size: H 2000 ×W 1450 × D 1500mm Usage: Weather Resistence Xenon Lamp Climatic Aging Test Chamber
Temperature Range: Rt+10°C ~80°C Light Source: Full Spectrum Xenon Lamp (air-cooled)
Spray Cycle: 1-240min, Interval Adjustable Spray Time: 1 To 9999min, Abjustable
Xenon Lamp Wavelength: 340~400nm Xenon Lamp Radiation Intensity: 0.25~0.55W/m2



Solar Radiation Xenon Lamp Exposure Aging Test Chamber for Paint LCD Touch Screen





Equipment summary:





Solar radiation xenon lamp exposure aging test chamber for paint , also known as "sunshine radiation protection test device", simulates full sunlight spectrum xenon arc lamp to represent the destructive waves under different environment. It is used for scientific research, product development and quality control to provide the corresponding environmental simulation and acceleration test. According to test standard and test method, It is devided into air cooling xenon lamp, air cooling xenon lamp and bench top xenon lamp. The differences for the three types are test temperature, test humidity, test time, etc.





Corresponding Chinese standard:


GB12831-86 Vulcanized rubber artificial climate (xenon lamp) Aging Test Method
GB/T1644.2-1999Plastics laboratory light exposure test method
GB/T8427-89 textile color fastness test, resistance to artificial light fastness xenon arc
GB/T8430-98 textile color fastness test, resistance to artificial light fastness xenon arc
GB/T1865-97 Paints, varnishes, artificial weather aging and artificial radiation exposure
GB/T16991-97 textile color fastness test,
GB/T5137.3-96 simulated climate test method of resistant to radiation, heat, humidity, burning
GB/T16259-96 color building materials, artificial climate accelerated aging test method.
GB/T2423.24-95 Electronic and Electrical Products Environmental Testing Part II: test method, testing SQ: Simulation of solar radiation on the ground.





Model KM-XD-720
Testing room W×H×D mm 950x800x950mm
index Temp.range RT+10°C~+80°C
Humi. range 50% to 98%R·H
rainfall time 1 to 9999min, continuous rainfall is adjustable
rainfall period 1-240min, interval and discontinuous is adjustable
wavelength 290nm to 800nm (200W/m2~800W//m2 is adjustable)
xenon lamp source water cooling type
Xenon lamp power 4 KW (longevity: 500H)

Control

system

Control way heat balcance adjust temperature way
Accourate range Temperature: ±0.1 degree / humidity: ±0.1R·H
Sensor Platinum resistance Pt 100Ω/mv
Heating system Independent system, nickel chromium alloy electric heating type heater
Humidity system stainless steel, external Isolated humidifier
Blackboard temperature Bimetal thermometer blackboard 55~75 degree
Water supply Humidification water supply with automatic control, xenon lamp cooled by water recycling
Temperature controller Import controller
humidity Irradiation: 30%~65%RH darkly: up to 90%RH
Cycle system low-noise air-conditioning-type motors, multi-leaf-type centrifugal wind wheel
material Outside material galvanized steel with power coated
Inside material SUS304 stainless steel
Specimen holder material SUS304 stainless steel
insulation High and low temperature aging of silicone rubber
accessories a set of radiation-proof glass window, dynamic testing sample shelf 1, xenon lamp tube 2
safety device Leakage, short circuit, over-temperature, water shortages, motor overheating, over-current protection.
Power supply AC380V±10% 50±0.5Hz , Three-phase five-wire system





Features:



1 equipped with blackboard thermometer to adjust the test temperature in the chamber.



2 can control xenon arc lamp light time.



3 Control water spray cycle.



4 Water circulation.



5 automatic constant temperature(circulating water cooling)



6 LCD touch screen controller can independantly control water spray, light, temperature, humidity, rotary table.



7 large glass observation window



8 water shortage and over temperature faulty alarm.



9 irradiation meter displays light intensity in the chamber.



10 Customization is welcomed and available.



11 Equipped with castors and feet, which helps users to move the test chamber easily.



12 One year free accessories maintenance.





Applicable industries of the climatic chamber:



Accelerated Weather Resistence Xenon Lamp Climatic Aging Test Chamber is applied to control the product quality, such as electronic, plastic products, electricalappliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care ..and so on.





Our Services



If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation manual. We can provide video-con.



1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.



2.Excellent After sale Service:


12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.



3.Commitment:


We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.



4.Good Packaging:



Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.





F A Q



1.Are your company a trading one or a factory?



Factory + trade (integration),27 years focusing on test instruments field,10 years exporting experience.



2.After an order is placed, when to deliver?



Generally about 25 days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.



3.What about the warranty with after - sales services?



12 months warranty. Besides,we can help you to repair your problem controller freely,even it's not from our factory. What you need to do is to send us the controller. After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product,handles guest problems and complaints in a professional and timely.



4.What about the services and product' quality?



Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.Product use training, each of our product provide video training to show you how to install & operate.All the products meet with: ISO, ASTM, AATCC, BS, EN, DIN, JIS and other requireable standards.







Also can supply:


Climatic test chambers , Power battery high and low temperature explosion proof testing chamber, Thermal shock test chambers, Walk-in chambers, Burn-in room and Aging test chambers, Drying ovens, Precision Oven Tester, Salt spray testers, Medical laboratory equipment etc.
