Product Details:
Payment & Shipping Terms:
|
| Standard: | Standard And Customized | HS Code: | 90321000 |
|---|---|---|---|
| Temp. Range: | 50º C-300º C | Volume: | 136L |
| Temperature Range: | Rt+20C To 250C | Housing Material: | Stainless Steel |
| Insulation: | Glass Wool | ||
| High Light: | laboratory drying oven,large industrial ovens |
||
1. Drying Oven Standard Version Features:
Nominal temperatures 250/300/350/400 °C;
Outer casing made of galvanized sheet steel, with coating blue, white color;
Corrosion-resistant inner casing made of galvanized sheet steel;
Low external wall temperature and minimal loss of energy due to high quality generously dimensioned thermal insulation of rock wool;
Grid rails in working chamber, facilitating height adjustment of wire-mesh shelves and grates;
The temperature-resistant door gasket is easily exchanged;
Door of walk-in units can be opened from inside;
Tubular heating elements made of stainless steel;
Safety temperature limiter (protects unit);
Microprocessor-based temperature controller with solid state relays ensures minimal control fluctuations;
Control panel with additional display and control elements which can be upgraded, thanks to its modular construction;
Exemplary air ducting system which enables an incredibly even temperature distribution to be achieved, even with a fresh air supply. The air in the working chamber is mixed in this system with fresh air sucked in via a heating register, mixed by the circulating air fan and conveyed once more to the working chamber.
Air exchange via air intake and exhaust flanges. Air intake flanges are closed by delivery.
2. Main technical specifications
Temp. fluctuation: ≤ ±0.5ºC
Temperature deviation: RT ~ +200 ºC ≤ ±2.0 ºC
+200 ºC~ +300 ºC ≤ ±3.0 ºC
Temp. constancy: ±1.0 ºC
Heat up time: 50 ºC to 200 ºC within 50 min
Control temperature means: Forced hot air circulation, ventlation mode
Interior material: Stainless Steel Plate
Exterior material: Baked painting steel
3. Industrial Drying Ovens Technical parameter
| Specifications | |||||||||
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 | KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm |
400* 350*350 |
450* 500*450 |
600* 600*600 |
600* 950*500 |
800* 1050*600 |
1000* 1000*600 |
900* 1000*800 |
1000* 1000*1000 |
1600* 1400* 600 |
| Exterior size (W*H*D)mm |
1010*650 *760 |
1110*800 *1100 |
1260*900 *1100 |
870*1590 *640 |
1160*1760 *880 |
1360*1715 *880 |
1300* 1750*1000 |
1400* 1750*1200 |
1600* 1940* 1200 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 | 6.5 | 7.5 | 8.5 | 9.5 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz | |||||||
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) | ||||||||
| Temp. constancy | ±1.0 ºC | ||||||||
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) | ||||||||
| Heat up time | 50 ºC to 200 ºC within 50 min | ||||||||
| Interior material | Stainless steel plate | ||||||||
| Exterior material | Painted Stainless steel plate | ||||||||
| Insulation material | Glass wool | ||||||||
| Safety devices | No fuse breaker, over temp protection, ceramic fuse | ||||||||
| Accessories | Recorder, insolating layer | ||||||||
|
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations |
|||||||||
4. Points you may concerned:
Ovens for Specific Applications
With its wide range of special application ovens, we can meet all your research and industrial needs, from plastics and electronics to pharmaceutical and car manufacturing.
Temperature precision
For specific heat treatment processes and drying of protective heat sensitive materials, we have a precise answer.
Safety for high-risk heating
Where there‘s a risk of fire, explosion or the release of aggressive gases or vapors, we offer a safe oven solution.
Material-specific
There are high precise drying ovens specifically designed for materials testing, including cable testing ovens for rubber and plastics.
Space saving
A choice of built-in and bench top ovens optimize your laboratory space.
Customized Products
We will work in partnership with you to tailor-make your oven to meet your particular specifications.
Competent advice
Explain your application need to our specialist and we will suggest the right product.
