Custom Stainless Steel Industrial Drying Oven Forced Hot Air Circulation


Custom designed Stainless Steel Industrial Drying Oven / Dryer Manufacturer

Over View

A drying oven uses controlled temperature to evaporate solvents (from drying paint, for example) or to dry wet materials (e.g., after washing). Its electric heating system can reach 300° C. Drying by simple convection is less efficient than forced convection using fans to circulate the air in the oven. Vacuum drying, even more efficient, involves lowering internal ambient pressure and aspirating the evaporating solvent, permitting low-temperature treatment of heat-sensitive materials.

Applications

These ovens are found in numerous research and production settings in the chemical, electronics, pharmaceutical and other industries.

How to choose

Choice depends on the materials to be dried, oven volume, maximum temperature and type of convection within the oven.


Standards Met and Implemented:
GB-2423．2-89(IEC68-2-2)Test B: High Temperature Test
GJB360．8-87(MIL-STD．202F) High Temperature Life Test
GBJl50．3(MIL-STD-810D) High Temperature Test


Main technical specifications
Temp. fluctuation: ≤ ±0.5ºC
Temperature deviation: RT ~ +200 ºC ≤ ±2.0 ºC
+200 ºC~ +300 ºC ≤ ±3.0 ºC
Temp. constancy: ±1.0 ºC
Heat up time: 50 ºC to 200 ºC within 50 min
Control temperature means: Forced hot air circulation, ventlation mode
Interior material: Stainless Steel Plate
Exterior material: Baked painting steel


South Korea imported thermostat controller ST-570

* Achieve high accuracy (0.1%), high-performance

* High resolution (0.1%), high performance

* Support multi-input (T / C, RTD, DCV)

* Can complete simultaneously output multiple output (Max 4 points)

* Simple parameter setting, text available

* Support suppression system(Overshoot) temperature function

* Alarm output 1 point

*RUN/STOP performance

* Default operation start and termination functions

* Operation screen displays of the auxiliary outputstatus

* Each interval input adjustment function (Max 4 Zone)

*Achieve control of heating, cooling function

* PID auto-adjustment function (AT Gain)

* Support for multiple communication protocols (Modbus, etc.)

* Achieve high-quality, high reliability (CE, CUL, ISO, etc.)

Standard Version Features:

Nominal temperatures 250/300

Outer casing made of galvanized sheet steel, with coatingblue, white color;

Corrosion-resistant inner casing made of galvanized sheet steel;

Low external wall temperature and minimal loss of energy due to highquality, generously dimensioned thermal insulation of rock wool;

Grid rails in working chamber, facilitating height adjustment of wire-mesh shelves and grates;

The temperature-resistant door gasket is easily exchanged;

Door of walk-in units can be opened from inside;

Tubular heating elements made of stainless steel;

Safety temperature limiter (protects unit);

Microprocessor-based temperature controller with solid state relays ensures minimal control fluctuations;

Control panel with additional display and control elements which can be upgraded, thanks to its modular construction;

Exemplary air ducting system which enables an incredibly even temperature distribution to be achieved, even with a fresh air supply. The air in the working chamber is mixed in this system with fresh air sucked in via a heating register, mixed by the circulating air fan and conveyed once more to the working chamber.

Air exchange via air intake and exhaust flanges. Air intake flanges are closed by delivery.


Temperature precision
For specific heat treatment processesand drying of protectiveheat sensitive materials, we havea precise answer.

Safety for high-risk heating
Where there‘s a risk of fire, explosionor the release of aggressivegases or vapors, we offer a safeoven solution.

Material-specific
There are high precise drying ovens specifically designed for materials testing,including cable testing ovens forrubber and plastics.

Space saving
A choice of built-in and bench topovens optimize your laboratoryspace.

Customized Products
We will work in partnership withyou to tailor-make your oven tomeet your particular specifications.

Competent advice
Explain your application need toour specialist and we will suggestthe right product.


Company information:
Being a first-class supplier and reliable partner, we are certified to ISO 9001 and got CE approval for all our products. All equipment are 7 x 24 hours tested before delivery. That explains why Komeg is the private brand of choice for many well-known brand enterprises, and also one of the very few designated suppliers who were recognized by many top 500 enterprises. Let Komeg's 26 years of professional experience work for you too.
