Product Details:
Payment & Shipping Terms:
|
| Temperature Range: | -20℃~+150℃ | Warranty: | 1 Year |
|---|---|---|---|
| Humidity Range: | 20~98%R.H | Certificate: | CE ISO |
| Interior Material: | Stainless Steel Plate ( SUS 304 ) | Heat Up Time: | -20℃~+100℃(within 35 Min) |
| High Light: | temperature and humidity chamber,temperature test chamber |
||
150L Programmable Temperature Humidity Chamber Adaptability And Standard Testing
Application
This product can be used in the following industry areas:
material, research institution, inspection,electronics, electrical appliance, battery, plastics, food, paper product, vehicle, metal, chemistry, building and quarantine bureau, university etc.
1. High - precision Floor Temperature And Humidity Chamber
High-quality and multi-function temperature test equipment is ideal for large test pieces.
Our products are equipped with user-friendly, comprehensive programming interface, through USB data retrieval and other functions.
Other user options are available, including rooftop ports and water cooling units.
2.The Type Of The Temperature Chambers
Performing high and low extreme temperature tests can change the mechanical and electrical properties of the product, such as component brittleness, lubricant viscosity, conductivity, and oscillator frequency. TRaC temperature test can simulate the temperature limit from -70 ° C to + 180 ° C (and up to + 500 ° C constant) cycle temperature limit.
3. Limits Of Test Chambers
Test room temperature threshold for the existence of reasons:
The test chamber typically has a wire heater made of a material called Nichrome. By placing a continuous ring of heater wires, a greater amount of heat is generated. The results look much like the inside of the toaster. The fan circulates the air through the heater, so the sample in the room is not exposed to radiant heat. It is very easy to add the heater and increase the speed and / or the upper limit of the chamber.
Our products usually have a high temperature limit at 200 ° C.
Here is why the high temperature limit of the room exists:
150 ° C: For two reasons, we may limit a chamber to 150 ° C. First, there may be restrictions on the materials used indoors. Secondly, for extremely fast chambers, we can limit the high temperature to avoid accidental tripping overheat protection devices.
170-180 ° C: Most models are stopped within this temperature range. There is a risk of burning oil in the cooling and cooling coil.
4. Parameter Specifications:
| Model | KMH-120L | ||||
| 120L chamber volume | |||||
| Temp. range | -20°C ～150°C | ||||
| Display resolution | 0.1°C | ||||
| Temperature stability | High±0.5°C ,low ±1.0°C | ||||
| Temperature uniformity | ±2.0°C | ||||
| Heat up time | -20°C ～+100°C, within 35 min | ||||
| Pull down time | +20°C ～-20°C, within 45 min | ||||
| Humidity range | 20～98％R.H,(standard), '10～98％R.H,(with humidifier) | ||||
| Humidity constancy | ±2.5％R.H | ||||
| Humidity uniformity | ±3.0％R.H | ||||
| Interior material | Stainless Steel Plate(SUS 304) | ||||
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | ||||
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | ||||
| Total power | 4.5KW(heater 2KW included) | ||||
| Max current | 9.1A | ||||
| Water Consumption | 0.35L/hr | ||||
| Power Supply | AC 380V±10％ 50Hz ,3 phase 4 wires +Ground Wires | ||||
| Sample holder | 2 pcs | ||||
| Fittings | cable port(portΦ50mm)*1, chamber lamp*1, power cable *2m | ||||
| Safety device (standard) | No fuse breaker,over pressure,over heat&over current protect,over temp. | ||||
| Control System | Balanced Temperature & Humidity Control (BTHC)System | ||||
| Refrigeration system | Air Cooled (Water Cooled is option) | ||||
| Hermetic compressor | |||||
Hermetic compressor | |||||
| Controller | 7-inch LCD Touch Screen panel | ||||
| Operation model :Program or fix point running | |||||
| Memory capacity :120programs,1200steps, | |||||
| All repeat 999 cycles, part repeat 99 cycles | |||||
Note: 1. We reserve the right to change specifications without prior notice | |||||
5. Features:
1. Customers can use the interface, integrated data logger and automatic control software programming and recording a wide range of options.
2. Corrosion resistant SUS # 304 stainless steel for studio and housing.
3. The concept of heating / cooling for specific products for accurate and uniform temperature control independent of chamber volume and load.
4. The temperature of the climate chamber is measured according to the relevant standard.
5. Each room has a safety test prior to work and has a CE test standard.
6. The cavity size and temperature range can be customized according to your requirements.
Fast and precise temperature control, no evaporator-dependent dry samples, no icing of the cooling unit, no dehumidification of the studio.
7. One year warranty, except for wear parts.
Our company has a variety of temperature and humidity chambers from small to small rooms that can reproduce a wide range of climatic conditions including high and low temperatures as well as combined temperature and humidity conditions. It also supports climate testing facilities specifically designed to test telecommunications and radio products.
7.Detail
