ESS - 408L Programmable ESS Chamber / Thermal Cycling Machine With LED Touch Screen

Certification
Good quality Temperature Humidity Chamber for sales
Good quality Temperature Humidity Chamber for sales
Fast delivery and quality products.

—— Gozia

Friendly and pleasant cooperator, "I like the factory, I like the design, I like the workstyle"

—— Wagner

The design and quality impress me a lot.

—— Mr Yee

" A trustworthy supplier of climatic test chamber".

—— Denis

I'm Online Chat Now

ESS - 408L Programmable ESS Chamber / Thermal Cycling Machine With LED Touch Screen

China ESS - 408L Programmable ESS Chamber / Thermal Cycling Machine With LED Touch Screen supplier

Large Image :  ESS - 408L Programmable ESS Chamber / Thermal Cycling Machine With LED Touch Screen

Product Details:

Place of Origin: China
Brand Name: KOMEG
Certification: CE, , ISO
Model Number: ESS-408L

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: By woodly case
Delivery Time: 45 days upon your deposit
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 1, 000 SETS / YEAR
Contact Now
Detailed Product Description
Heat Up Time: -55℃~+150℃,within 60 Min Custom Made: Available
Working Volume: 408S Humidity Range: 20~98%R.H
Temperature Uniformity: ±2.0º C (with Empty Load) Controller: LED Touch Screen
Compressor: Danfoss Or Tecumseh Or Blog Wiring Method: AC 380±10% 50Hz ,3 Phase 4 Wires +Ground Wires

ESS-408L Programmable ESS Chamber thermal cycling machine for Highly Accelerated Life Test



Applications

Rational Construction and fast cooling rate

Frequency conversion control of wind speed.

Adopts international brand of imported parts for cooling system to improve operation reliability

Touch screen controller, friendly Man-Machine interface and safety device to ensure simple operation and easy maintenance.

Wide variety of refrigeration available for performance and temperature range flexibility.

Programmable LCD touchscreen controller for product or air-change available.



Features

A. Reliability testing based on current test standards in the temperature range of -40 °C to 180 °C and 10% to 98% R.H.

B. The ideal simulation chamber for all heat and cold testing in the traditional temperature range -40 ºC and 150 ºC.

C. Forced ventilation loops design, balance temperature & humidity control system (BTHC).

D. We can provide custom-made machine and optional accessories satisfied your special requirements.

E. Improved programming and data collection via computer

F. Energy-saving operation, the KM-5166 controller uses advanced control of an electronic expansion valve to save energy and improve control of the refrigeration system. Improvements in refrigeration and heater operation make the new generation of KOMEG environmental test chambers the most energy efficient ever.



Standards Implemented and met

●GB10592-89 Technical requirements for high and low temperature test chamber
●GB2423.1-1989 Low temperature test mode
●GB2423.2-1989 High temperature test mode

●GJB150.3-1986 High temperature test mode

●GJB150.4-1986 Low temperature test mode

●GJB150.9-1986 Warm test method





Standard configuration

●Stainless steel exterior

●Energy-efficient refrigeration with exclusive electronic expansion valve system

●Specialized humidity generation and control

●Unique thermal break construction for extreme testing

●Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m
●No fuse breaker, over pressure
,over heat and over current protection for compressor, Over temperature protection, over load protect of blower, dry heat protection



Optional accessories

●Cable Port: Φ100mm cable port is available
●Shelves
●Ro-type water purifier:R-80/day
Provide to keep the humidifying heater and wet bulb wick free from scale.
●Inner glass door with operation port
A glass door can be provided behind the main door so that specimens can be observed. Two operation ports of 130mm diameter are used for handing specimens inside the chamber without opening the glass door.
●Dehumidifier
The rotation regenerating dehumidifier M-120 ensures precise control of low humidity (5℃ 5%RH) for electrostatic reliability tests.
●Temperature and humidity recorder
Temperature 1 pen and humidity 1 pen.
Temperature 3 dots and humidity 1 dot.
Temperature 6 dots and humidity 6 dots.
●Defrosting circuit
The chamber automatically detects and melts the frost on the evaporator when operating below 0℃.
●Liquid or infection
In order to rapidly decrease the temperature inside the chamber, a cylinder of liquid can be connected the chamber

serif!z lr�F �L mso-font-kerning:0pt'>



F. Energy-saving operation, the KM-5166 controller uses advanced control of an electronic expansion valve to save energy and improve control of the refrigeration system. Improvements in refrigeration and heater operation make the new generation of KOMEG environmental test chambers the most energy efficient ever.



Material:

Interior material: Stainless Steel Plate SUS304#

Exterior material: Baked Painting Steel Plate or Stainless Steel SUS304#

Insulation material: Rigid polyurethane Foam and Glass Fiber Wool



Refrigeration system:

Water Cooled

Hermetic compressor, stag refrigeration system





Advantages :

Benefits more than you can get from other supplier.

1)Delicate touch and excellent user experience

2)Unique and compact design, top grade appearance, stable performance and easy operation.

3)Can simulate a wide range of temperature and humidity environments

4)Capable of testing large components, assemblies, and finished products

5)Customized sizes and configurations available



National laboratory

Programmable ESS Chamber thermal cycling machine  for Highly Accelerated Life Test



Some environmental test chamber details

Programmable ESS Chamber thermal cycling machine  for Highly Accelerated Life Test

Programmable ESS Chamber thermal cycling machine  for Highly Accelerated Life Test



Part of the certificate for KOMEG test chamber

Programmable ESS Chamber thermal cycling machine  for Highly Accelerated Life Test





Specifications

Model ESS-SL
408 SL5
Working Chamber Volume(L) 408L
Temp Rate of Change( ºC /Min) 15 ºC /Min
Temperature Range -70 ºC~+100 ºC( Rapid Temp Change -55 ºC~+85 ºC Full Linear Control)
Humidity Constancy ±0.5 ºC
Temp Constancy ±3.0 ºC
Exterior Material Cold-rolled steel sheet (Rust proof & Plastic Spray treated )/ Stainless Steel
Interior Material Stainless Steel Plate(SUS 304)
Insulation Material Rigid Polyurethane Foam
Safety Devices over pressure,over heat and over current protection for compressor, over temp. protection,
Compressor Semi-Hermetic Compressor
Cooling Mode Water Cooled
Control system Balanced Temperature & Humidity Control System(BTC type)
Heater Iron-chrome wire heater
Blower Centrifugal Blower
Observation Window Glass incorporating heat generator
Temp Sensor Pt-100
Controller Touch screen programmable controller
Ambient Temp. +5ºC~+35ºC
Power AC 380V/50Hz 3phase 5 wires+ Ground wire
Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available
