1270L Nonlinear 7 ℃ Papid Thermal Change Chamber

1270L Nonlinear 7 ℃ Papid Thermal Change Chamber
1270L Nonlinear 7 ℃ Papid Thermal Change Chamber 1270L Nonlinear 7 ℃ Papid Thermal Change Chamber 1270L Nonlinear 7 ℃ Papid Thermal Change Chamber 1270L Nonlinear 7 ℃ Papid Thermal Change Chamber

Large Image :  1270L Nonlinear 7 ℃ Papid Thermal Change Chamber

Product Details:
Place of Origin: China
Brand Name: KOMEG
Certification: CE, ISO
Model Number: ESS-1270S-SC07
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotiation
Packaging Details: Rigid foam and wooden box
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 1, 000 SETS / YEAR
Detailed Product Description
Cooling Mode: Water Cooled Heater: Iron-chrome Wire Heater
Interior Material: Stainless Steel(SUS04) Exterior Material: Baked Painting Steel Or Stainless Steel(SUS04)
Controller: Touch Screen Programmable Controller Temp Range: -70ºC~+150ºC
High Light:

Nonlinear Thermal Change Chamber


1270L Thermal Change Chamber

1270LNonlinear 7 ℃ papid thermal change chamber with explosion-proof device


The Rapid-Rate Thermal Cycle Chamber is ideal for test requiring quick changes 15°C/min ramp rate in


specimen temperature and 23°C/min ramp rate for air temperature. It covers various applications from


JEDEC, IEC standards to screening.


It features new technologies, such as a specimen temperature control function maintaining linear


specimen temperature change rates during rapid thermal cycling, and temperature ramp control.





Rational Construction and fast cooling rate


Frequency conversion control of wind speed.


Adopts international brand of imported parts for cooling system to improve operation reliability


Touch screen controller, friendly Man-Machine interface and safety device to ensure simple operation


and easy maintenance.


Wide variety of refrigeration available for performance and temperature range flexibility.


Programmable LCD touchscreen controller for product or air-change available.





Model ESS-408S
Insaide dimension(W*H*D)cm 70*75*80
Performance Temp.range -40℃ ~ +150℃
Temp.fluctuation ±0.5℃
Temp.deviation ±2.0℃
Rapid Temp Chang Rapid Temp Change+150℃~-60℃
Full Linear Control 5℃/min,Rapid Temp Change-60℃~+150℃
Full Linear Control 5℃/min,
Temp.regulating methods BTC methods
Material Science Interior material Stainless Steel (SUS304)
Exterior material Baked Painting Steel Or Stainless steel(SUS304)
Insulation material Rigid polyurethane Foam
Refrigeration system Refrigerator cascade refrigeration system
Cooling Mode Water Cooled
Heater Iron-chrome wire heater
Blower Centrifugal Blower
Door window Glass incorporating heat generator
Temp sensor Pt-100 Platinum resistance
Controller Touch Screen Programmable Controller
Safety device Over protection,over-heat,over-current protection for compressor,over-temperature protection,over-load protection for blower,hydraulic and lack of water protection,leakage protection
Standard configuration Observation window,Cable port,(Ø50mm,1piece for both left and right side),baffle(2sets),chamber lamp
Select accessories RS-232C,recorder,special cable port,special specimen holder,additional baffle
Power AC 380V/50HZ 3phase4wires+Ground wires



Standards Implemented and Met


GB10592-89 Technical requirements for high and low temperature test chamber


GB2423.1-1989 Low temperature test


GB2423.2-1989 High temperature test mode



Photos details


1270L Nonlinear 7 ℃ Papid Thermal Change Chamber 0





Packing details


We use PP Film wrapping the test chamber to protect the test chamber from moisture or being scratched


first, then use strong plywood case for easyload and transport, and to keep the chambers from potential


crash or impact.


1270L Nonlinear 7 ℃ Papid Thermal Change Chamber 1



After-sale Service:

If you face any problems in future during testing process we promise we will give you a reply within 48


hours and solution provide within 3 working days. We can offer operation video and English operation


muanual. We can provide video-conference. If customers require on-site service, the transport and travel


expense shall be borne by customer.
