PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control

PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control
PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control

Large Image :  PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: KOMEG
Certification: CE//ISO
Model Number: KMH-1500L
Payment & Shipping Terms:
Minimum Order Quantity: ONE SET
Price: 12000USD~20000USD
Packaging Details: The normal package is the wooden box.(Size:W*H*D)
Delivery Time: 30 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 set per month
Detailed Product Description
Humidity Range: 20~98%R.H Controller: LED Touch Screen
Working Volume: 1500L Temperature Uniformity: ±2.0º C (with Empty Load)
Compressor: Danfoss Or Tecumseh Or Bock Wiring Method: AC 380±10% 50Hz ,3 Phase 4 Wires +Ground Wires
Temperature Fluctuation: ±0.2C Temperature Uniformity: ±1.5C
Humidity Resolution: 0.1%RH Humidity Fluctuation: ±0.5%RH
High Light:

led light testing equipment

,

led testing instruments



PCB and LED Resistance Cold Heat Shock Test Chamber Specifications Touch Screen Control





Product description :





Heat shock test chamber is used to test the bearing extent of the material structures and composite material in an instant and continuous high temperature and extremely low-temperature environment, which is in the shortest time to test its thermal expansion and contraction caused by a chemical change or physical harm. Application objects, including metal, plastic, rubber, electronics ... and other materials can be used as a basis to improve their products or reference.





Application:



Test material heat, cold, dry resistance, humidity resistance.Suitable for electronics, electrical appliances, communications, instrumentation, vehicles, plastic products, metal, food, chemical, building materials, medical, aerospace and other products.





Specifications:





Model KMH-1500L
1500L chamber volume
Temp. range -40°C ~150°C
Display resolution 0.1°C
Temperature stability High±0.5° C, low ±1.0°C
Temperature uniformity ±2.0°C
Heat uptime -40°C ~+100°C, within 45 min
Pull downtime +20°C ~-40°C, within 60 min
Interior Dimension(mm) W 1500 × D 1000 × H 1000 mm
Exterior Dimension(mm) About: W2010 x D1510 x H 2150 mm
Interior material Stainless Steel Plate ( SUS 304)
Exterior material Baked Painting Steel Or Stainless steel ( SUS304)
Insulation material Rigid polyurethane Foam and Glass Fiber Wool
Total power 7KW(heater 3KW included)
Max current 13.6A
Ambient Temp. +5°C ~+35°C
Power Supply AC 380V±10% 50Hz, 3 phase 4 wires +Ground Wires
Weight 420KG
Sight window size 430 X 530mm
Sample holder 2 pcs
Fittings cable port(portΦ50mm)*1, chamber lamp*1, power cable *2m
Safety device (standard) No fuse breaker,overpressure, over heat&over current protect, over temp.
protect, overload protect for the blower, dry heat protect
Control System Balanced Temperature & Humidity Control (BTHC)System
Refrigeration system Air Cooled (Water Cooled is an option)
Hermetic compressor
Single-stage refrigeration system,
CFC-Free refrigerant(HFC-507/HFC-23)
Controller 7-inch LCD Touch Screen panel
Operation model : Program or fixpoint running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles

Note:

1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available







Features:







1. The TFT LCD touch panel controller was made in Japan, can display Chinese / English. Big size TFT LCD panels are also adopted.



2. High formula memory capacity can be set to 120 patterns. The maximum cycle setting is 9999 times. The maximum setting time of each pattern is 9999 Hrs 59 Mins.



3. Provide with RS-485C communication interface device, capable of controlling / editing/ recording in the linkage with the computer and two set dynamic connection point and convenient application.



4. Both 2 zone and 3 zone shocks can be chosen.



5. All equipment is fully automatic, and all process is precisely controlled with P.LC' s.



6. If any parts have errors, the machine will automatically shut down and a warning light switches on.



7. The machine can be shut down automatically in case of electrical power instabilities.









Standards Implemented and met :



●GB10592-89 Technical requirements for high and low-temperature test chamber


●GB2423.1-1989 Low-temperature test mode


●GB2423.2-1989 High-temperature test mode



●GJB150.3-1986 High-temperature test mode



●GJB150.4-1986 Low-temperature test mode



●GJB150.9-1986 Warm test method





Standard configuration :



●Stainless steel exterior



●Energy-efficient refrigeration with exclusive electronic expansion valve system



●Specialized humidity generation and control



●Unique thermal break construction for extreme testing



●Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m


●No fuse breaker, overpressure, overheat and over current protection for compressor, Over temperature protection, overload protection of the blower, dry heat protection





Optional accessories :



●Cable Port: Φ100mm cable port is available


●Shelves


●Ro-type water purifier: R-80/day
Provide to keep the humidifying heater and wet bulb wick free from scale.


●Inner glass door with operation port
A glass door can be provided behind the main door so that specimens can be observed. Two operation ports of 130mm diameter are used for handing specimens inside the chamber without opening the glass door.


●Dehumidifier
The rotation regenerating dehumidifier M-120 ensures precise control of low humidity (5℃ 5%RH) for electrostatic reliability tests.


●Temperature and humidity recorder
Temperature 1 pen and humidity 1 pen.
Temperature 3 dots and humidity 1 dot.
Temperature 6 dots and humidity 6 dots.


●Defrosting circuit
The chamber automatically detects and melts the frost on the evaporator when operating below 0℃.


●Liquid or infection
In order to rapidly decrease the temperature inside the chamber, a cylinder of liquid can be connected to the chamber





F. The energy-saving operation, the KM-5166 controller uses advanced control of an electronic expansion valve to save energy and improve control of the refrigeration system. Improvements in refrigeration and heater operation make the new generation of KOMEG environmental test chambers the most energy efficient ever.





Minimum Order Qty: 1 unit
Price: Negotiable
Payment Terms: T/T, negotiable
Warranty 12 months on parts (excluding the damages caused by natural disasters, abnormal power, improper operation, and maintenance, etc)
Delivery Time: 60 working days after received a 60% deposit
Packaging Details: Packed in carton firstly, and then reinforced with plywood case for outer packing





Our Services





1, Pre-sales service



Before the purchase, our company will provide customers with detailed product-related information, and welcome you to visit the company and check the goods.



2, After-sales service



After the completion of the transaction, our company will be arranged different after-sales service according to the ease of the goods, and even arrange work engineers on-site service.



3, the Warranty period



Our product warranty is 12 months and we are committed to responding within 48 hours of the problem, providing a solution.



FAQ



1. How long will it take from order placement to goods delivery?

We have a perfect ERP system and BOM table for each machine,

the delivery time including debugging is 35~50 days



2. What are your advantages?

KOMEG has 29 years of experience in producing environmental chamber and 13 processes and 5 times quality control to ensure the accurate control of all details for the environmental chamber



3. Which certifications do you have?

We have passed the CE certification, ISO certification, China high-tech enterprise certificate, military-civilian integration enterprise certificate, etc.



4. How is the product delivered?

Generally, the customer will choose sea transportation within 30 days, but European countries can also choose the central European train within 15 days. If it is urgent, the customer can choose air transportation, but the air transportation cost is relatively high



5. Is there a variety of language options for your operating system?

We use KOMEG controller system, it has Russian, English, Chinese,

Korean and other languages. (customizable)





6. Which countries have your product sold to?

We have sold to so many countries, such as Russia, America, Korea, Denmark, Vietnam, Singapore, South Korea, Pakistan, Turkey, Germany and other more than 20 countries.





7. How long the warranty of your environmental chambers covered?

We provide free parts replacement service for accessories with one year. We will supply free parts during the machine's warranty period if the machine has some problems. While we also supply free life long after-sales service.



8. How can you provide a solution if your products break down?

Our engineers will analyze the problems which you raised, and we can build a group through video phone, WeChat, Skype and Whatsapp to guide you to solve the problems step by step. At the same time, we will provide complete instructions, circuit diagram, freezing diagram, structure book, and fault analysis solutions; If you need our engineers to repair door to door, you only need to provide air tickets and accommodation;



9. How to install and use the product?

The product is shipped with operating instructions, drawings, and videos of the English version.

At the same time, we also recommend that customers who buy our products for the first time use door-to-door installation service;



10. How is the product packed?

1: The first step is to keep the equipment clean with a high toughness tensile membrane.

2: The second step is to use a high strength paper corner to prevent equipment from scratches, bump.

3: The third step is to use a thick bubble bag to prevent the damage caused by friction.

4: The fourth step is to use tension rope to fasten.

5: The last step is to use the standard wooden cases.
