High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers

China KOMEG Technology Ind Co., Limited certification
China KOMEG Technology Ind Co., Limited certification
Fast delivery and quality products.

—— Gozia

Friendly and pleasant cooperator, "I like the factory, I like the design, I like the workstyle"

—— Wagner

The design and quality impress me a lot.

—— Mr Yee

" A trustworthy supplier of climatic test chamber".

—— Denis

I'm Online Chat Now

High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers

High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers
High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers
video play

Large Image :  High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers

Product Details:
Place of Origin: China
Brand Name: KOMEG
Certification: CE/ROHS/ISO/TUV
Model Number: KMHW-45
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 45 working days after received your payment
Supply Ability: 20 sets per year
Detailed Product Description
Temp. Range: Maximum:80℃, 120℃; Minimum: -60℃, -50℃, -40℃, -30℃, -20℃, -10℃, 0℃ Relative Humidity Range: 20%~95%/ 30 ℃ To 85 ℃
Temp. Constancy: ±0.5℃ Humidity Constancy:: ±2.5%R.H
Humidity Uniformity: ±5.0%R.H Test Volume(M3): 45 Cubic
Temperature Ramp Rate: 1 ℃/ Min Temperature Loaking Rate: 2 ℃/ Min
Temperature Uniformity: ± 2℃
High Light:

walk in environmental chamber

,

walk in humidity chamber

CE Standard Temperature and humidity Simulation temperature test chamber room with temperature greater than +93°C (+200°F)

Applications

It is suitable for large parts and machineries undergone low to high and high to low temperature change test, constant hot test, temperature/humid alternating test. User can make to order according to their needs for the room size and test requirements .biological equipment, etc. Outside banding helps prevent leaking and keeps moisture out of the Walk-In Chamber and workspace temperatures steady.

Solid Walk-In Chambers are custom built to accommodate almost any size. They feature welded walls creating an environmental room for applications requiring controlled temperature and humidity testing exceeding 85°C. Typically, for ease of installation, a Solid Walk-In Chamber works best in new construction buildings, areas with extremely large doors, or rooms where outside walls can be easily removed.


Features

1) Stainless steel interior
2) Painted galvanized steel exterior for long life
3) MAP service doors are hinged (no tools or lifting)
4) Easy access to frequently checked refrigeration components
5) Reliable steam generator system for humidity applications
6) Adjustable vanes in supply grille allow directing of airflow as needed
7) Control method and characteristics:
Precision microcomputer control temperature and humidity system, with PID control the refrigerant flow to make the system’s heating / humidification reduction, to achieve low power consumption, energy saving, carbon reduction effect, cooling, heating, humidity control intelligent electronic control, long-term stable use.



Standard Met and Implemented:



GB/Bb T2423.2-89 high temperature test method

GB2423.1-89 test A: low temperature test method 6

GJB150.4-1986 test at low temperature

IEC60068-2-1 low temperature test method

IEC60068-2-38 temperature cycle

IEC60068-2-78 constant humidity temperature

IEC60068-2-1.1990 testing methods for low-temperature

IEC60068-2-2.1974 testing methods for high-temperature

GJB150.3 High-temperature test

GJB150.4 Low-temperature test

GJB150.9 muggy test

GB/T2423.22 temperature test


Description
Most popular walk-in type

Standard sub-assemblies for quick delivery and low cost

High quality panels manufactured to KOMEG standards.

Standard muti-layer heated window in door(s)

Operation allowable to 120°C(75°C in humidity mode )

Temperature change rates to 10°C/m.



High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers 0

Flexibility for structure
The panels used in our chamber are 4” (100mm or 150mm) Thick urethane-foam sandwiched between a stainless-steel interior wall and a coated-steel exterior. An assembled box is self-supporting. So that no heavy structural members are required. Different door sizes, flooring upgrades,access ports, and other modifications are possible.



Advantages:



Structure:

Our housing are high-quality carbon steel with static color spray outside and galvanized steel sheet inside. Sheet metal processing machines are from Germany. Trumph is famous for its precise bending technology, so our products outlook looks quality, precise and neat.



Refrigerating System:

We use tube bending machine for copper tube bending, this way can decrease the welding points. This is easy to keep the copper tube clean to ensure longer service life of the compressor. Also less welding points can reduce the resistance when the liquid flowing inside, to keep compressor working in higher efficiency, and better energy-saving.



Water and electricity system separating design:

For improving the comparable fragile part, heating part of constant high damp heat test, we apply water and electricity system separating design, to keep the water and electricity system separated with external humidifying system, and use top brand(e.g.: DANFOSS, Schneider, Danfoss, Emerson, Saginomiya, etc. ) for all electronic components to make sure the chambers’ quality and service time.



Please check below operating technical parameter and contact us now for more details.
Model KMHW-45
Volume(m³) 16.8CBM
Interior Dimensions W3000 x H3000 x D5000mm
Exterior Dimensions depends on design
Safety Devices(standard) No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection
Standard accessories Sight window*1, cable port ( portΦ50mm ) *1, chamber lamp*1, status indicator
Control System Balanced Temperature & Humidity Control System
Refrigeration system Water Cooled
Semi-hermetic compressor, single stage or cascade refrigeration system,
CFC free refrigerant ( HFC-507 and HFC-23 )
Controller Panel 7-inch LCD Touch panel, Chinese or English display selectable
Operation model Program or fix point running
Memory capacity 120 programs,1200steps, all repeat 999 cycles,part repeat 99 cycles
Accuracy Temp.:0.1% of F.S ± 1 digit Humidity:0.1% of F.S ± 1 digit
Input Temp.: pt-100, Humidity: pt-100 or ~5V DCV
Comm.port RS-232 or RS-485 ( Softawre is option)
Temp. range Maximum: 80 ºC,120 ºC;
Minimum: -60 ºC, -50 ºC, -40 ºC, -30 ºC, -20 ºC, -10 ºC, 0 ºC
Humidity Range 10%, 20%, 30% ~ 95%
Temp. constancy ±0.5 ºC
Humidity constancy ±2.5%R.H
Temp. uniformity ±2.0 ºC
Humidity uniformity ±5.0%R.H
Ambient Temp. +5 ºC~+35 ºC
Wiring method AC 380 ± 10% 50Hz ,3 phase 4 wires + Ground Wires
Heat up time +20 ºC~+80 ºC, Within 60 min
Pull down time +20 ºC ~ -55 º, -40 ºC, -20 ºC, -10 ºC, Within 120 or 90 or 60 min
Interior material Stainless Steel Plate(SUS 304)
Exterior material Baked Painting Steel Or Stainless steel ( SUS304)
Insulation material Rigid polyurethane foam
Door size (mm) Single wing: W800 x H1800; Double wing: W1600 x H1800;
Note:1. We reserve the right to change specifications without prior notice
2.Customized sizes and configurations available

High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers 1
High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers 2
High Precise Energy Saving Walk-In Chamber / Stability Environmental Test Chambers 3
